Shure PGX4=-J6 Diversity Receiver with PS21US Power Supply
Shure PGX4=-J6 Diversity Receiver PGX4=-J6
SKU: SHPGX4J6 MFR: PGX4=-J6
Please note! This is a Special Order Item and is Non Cancelable and Non Returnable.
We Charge you when you place your order. Approximate arrival at Adorama 1 - 2 Weeks from date of order.
What's Included
What's Included With This Item:
- Shure PGX4=-J6 Diversity Receiver
- Power Supply
- User Guide
- Shure Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Shure PGX4=-J6 wireless microphone receiver is designed for use with the PGX1 and PGX2 wireless transmitters. The receiver operates over an 18 MHz UHF bandwidth with the flexibility of selecting up to 90 UHF frequencies. The diversity design enables dual internal receiver circuits to compete for the strongest possible reception. The result minimizes noise and RF interference. The rear panel features XLR and 1/4" phone outputs. An infrared port enables frequency information to sync with the transmitter remotely.
- Shure PGX4=-J6 Diversity Receiver
- Power Supply
- User Guide
- Shure Warranty
- Frequency Agile UHF: The PGX series wireless microphone systems provide up to 90 selectable UHF frequencies and operate on an 18 MHz UHF bandwidth
- Infrared Sync Port: The PGX series transmitters and receiver feature infrared remote synchronization of channel and frequency status
- Diversity Reception: The PGX4 receiver features twin receiver circuits that compete for the strongest possible RF reception. The result minimizes noise and drop out caused by RF interference
| Type of Receiver |
PGX4 Rack/Table Top Mountable UHF Diversity Receiver |
| RF Carrier Frequency Range |
H6/524 - 542MHz |
| Approx. Working Range |
300 Feet (91.4m) |
| Overall Frequency Response |
45 Hz - 15 kHz, +/-2dB |
| Signal-to-Noise Ratio |
> 100dB A-weighted |
| # Of Channels |
90 Selectable Frequencies |
| Type of Output(s) |
3-pin XLR: 200 ohms
1/4" Phone: 1k ohms |
| Housing |
ABS |
| Headphone Monitoring |
No |
| Power Requirements |
12-18 Vdc @ 150 mA, supplied by external power supply |
| Display |
LCD Display: Frequency & Group Status |
| Mounting Options |
Rack mountable with optional URT rack-mount tray |
| Antenna Type |
Dual 1/4 wave antennas |
| Dimensions (H x W x D) |
1.6 x 7.125 x 4.1" (40 x 181 x 104mm) |
| Weight |
11.5 oz (327 g) |
