| Magnification |
8 x |
| Front lens diameter |
42 mm |
| Exit pupil |
5.3 mm |
| Twilight factor |
18.3 |
| Field of view at 1,000 m |
125 m |
| Field of view at 1,000 yds |
368 ft |
| Eye-relief |
18 mm |
| Objective angle of view |
7° |
| Close focusing distance |
Approx. 5.6 m/18.4 ft |
| Diopter compensation |
± 3.5 diopters |
| Distance measurement Range |
10 m to approx. 1,300 m/10 yds to approx. 1,400 yds |
| Distance measurement Accuracy |
± 1 m/yd up to 350 m/380 yds
± 2 m/yds up to 700 m/763 yds
± 0.5 % beyond 700 m/763 yds |
| Read-outs |
LED display with four digits, easily legible in any light |
| Eyepieces for eyeglass wearers |
Yes |
| Sliding eyecups |
Yes, removable, with two click stops |
| Adjustable interpupillary distance |
56-74 mm |
| Focusing |
Internal focusing via central focusing device |
| No. of lens elements (each side) |
7, with Leica AquaDura coating |
| Prism system |
Roof prism with phase correction coating P40 |
| Watertightness |
Watertight to a depth of 5 m/16.5 ft |
| Housing |
Die-cast aluminium, nitrogen-filled |
| Meter / Yard selector |
No |
| Laser |
Eye-safe invisible laser according to EN and FDA class1 |
| Laser beam divergence |
2.5 x 0.5 mrad |
| Measuring time |
Max. approx. 1.4 s |
| Measuring mode |
Scanning mode |
| Power supply |
1 x 3V/Lithium-type C2R |
| Battery lifetime |
Approx. 2,000 measurements at 20°C/68°F |
| Neopren carrying strap, contoured |
Included |
| Dimensions (W x H x D) |
125 x 173 x 70 mm / 4-7/8 x 6-3/4 x 2-3/4 in |
| Weight |
Approx. 950 g/33.5 oz incl. batteries |
| Warranty |
Leica warranty |
