The AJA Ki Pro Rack has video facilities transitioning from tape to file-based workflows for recording and playback. Ki Pro Rack offers high-quality, 'ready-to-edit' file capture, designed to get material from source to editorial as quickly as possible. With a wealth of professional connections, Ki Pro Rack will fit right into your existing cabling and routing system and record 10-bit Apple ProRes and Avid DNxHD files direct to removable hard disk or SSD Storage Modules, eliminating the need for time-consuming logging and capturing. The files can be used in most editing systems without the need for additional transcoding or importing processes.
| Video Input | Digital:1 Channel, selectable input SD and HD-SDI (2xBNC), SMPTE-259/292/296 HDMI Analog: SD/HD Component (3xBNCS): SMPTE/EBU N10, Betacam 525 line, Betacam 525J, YPbPr 12-bit A/D, 2x oversampling |
| Video Output | Digital: SD and HD-SDI, SMPTE-259/292/296 (1xBNC) HDMI Analog: Composite (1xBNC): NTSC, NTSCJ, PAL 12-bit D/A, 8x oversampling SD/HD Component (3xBNCs): SD: SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB 12-bit D/A, 8x oversampling HD: YPbPr, RGB 12-bit D/A, 2x oversampling |
| Audio Input | Digital: AES 24-bit, 8 channel, 48kHz (4xBNC) 24-bit SDI embedded audio, 8 channel, 48kHz HDMI embedded, 2 channel Analog: 24-bit A/D, 2 channel balanced (2 XLR), 48kHz Input level: Line |
| Audio Output | Digital: AES 24-bit, 8 channel, 48kHz (4xBNC) 24-bit SDI embedded audio, 8 channel, 48kHz HDMI embedded, 2 channel Analog: 24-bit D/A, 2 channel balanced XLR, 48kHz |
| Network | 10/100/1000 Ethernet (RJ45) Embedded web server for remote control |
| Panel User Interface | 2 x 20 character display, with dedicated buttons |
| Timecode | LTC timecode input and output via BNC SDI embedded RP188 timecode On-screen timecode display on SDI 2 output |
| Serial Port | RS-422 (slave pinout), 9-pin (available beginning with version 2.0 firmware) Connector pinout is as follows: 1 GND 2 TX - 3 RX + 4 GND 5 No Connection 6 GND 7 TX + 8 RX - 9 GND Shell GND |
| Hardware up conversion - 10-bit | Anamorphic: full-screen Pillar box 4:3: results in a 4:3 image in center of screen with black sidebars Zoom 14:9: results in a 4:3 image zoomed slightly to fill a 14:9 image with black side bars Zoom Letterbox: image zoomed to fill screen Zoom Wide: combination of zoom and horizontal stretch to fill 16:9 screen; this setting can introduce a small aspect ratio change |
| Hardware down conversion - 10-bit | Anamorphic: full-screen Letterbox: image is reduced with black top and bottom added to image area with the aspect ratio preserved Crop: image is cropped to fit new screen size |
| Hardware cross conversion - 10-bit | 1080i to 720P 720P to 1080i |
| Storage Module drive bays | 2 (each with eject button and select LED) |
| Temperature | Operating Temperature Range: 5Deg.C to 40Deg.C Safe Storage Temperature Range (power OFF): -20Deg.C to 60Deg.C |
| Power | Voltage: 100-240 VAC Typical operating power: 40W |
| Dimensions (H x W x D) | 1.75" x 19" x 12.5" / 4.45 x 48.26 x 37.75 cm |
