| Standard Definition or High Definition |
High Definition |
| Power Supply (rated) |
7.4V DC (battery pack) |
| Video Recording system |
Compression: MPEG-2 Long GOP Color Space: 4:2:2 (at 50Mbps recording) File Format: MXF Recording Modes: 50Mbps (CBR) 4:2:2, 1920x1080, (60i/30p/24p), 1280x720 (60p/30p/24p) 35Mbps (VBR) 4:2:0, 1920x1080 (60i/30p/24p), 1280x720 (60p/30p/24p) 25Mbps (CBR) 4:2:0, 1440x1080 (60i/30p/24p) |
| Audio Recording system |
2-Channel, PCM digital recording, 16-Bit; 48kHz |
| Image Sensor |
1/3-inch CMOS |
| Total Pixels |
Approx. 2.37 megapixels (2044 x 1160 pixels) |
| Effective Pixels |
Approx. 2.07 megapixels (1920 x 1080 pixels) |
| Maximum recording Time |
64GB Compact Flash (CF) card Greater capacity is possible when two cards are used. 25Mbps: 310 minutes 35Mbps: 225 minutes 50Mbps: 160 minutes |
| Lens |
Canon 10x HD Zoom Lens, 4.25-42.5mm (35mm equivalent 30.4-304mm), f/1.8-2.8 |
| Focusing System |
TVAF plus External Phase Difference Metering Sensor, Autofocus (Instant AF, Medium AF, Normal AF, Face AF, Face Only AF), Manual, Full Manual |
| Max Shutter Speed |
1/2000 |
| Minimum Focusing Distance |
20mm (wide macro), 60cm (entire zoom range) |
| White Balance |
Auto, Manual, Custom (2000K - 15000K in 100K increments), Daylight, Tungsten |
| Frame Rate |
60i, 60p, 30p, 24p (50i and 25p optional upgrade available through Canon Factory Service Center) |
| Minimum Illumination |
Full AUTO mode: 4.5 lux (Shutter speed 1/60, Gain +24dB); Manual mode: .11 lux (shutter speed 1/4, Gain +33dB), (when 60i is selected) |
| Genlock Terminal |
BNC (input only) Same terminal as Time Code |
| HD/SD-SDI Terminal |
BNC (output only), with embedded audio and time code |
| Timecode Terminals |
BNC (input/output) Same terminal as Genlock |
| Image Stabilization |
SuperRange Optical (Lens Shift) 4 modes: Standard, Powered, Dynamic, Off |
| Filter Diameter |
58mm |
| Viewfinder |
0.24-inch color widescreen, approx. 260,000 dots, approx. 100% field of view |
| LCD Screen |
3.5-inch color widescreen LCD, approx. 920,000 dots, approx. 100% field of view |
| Microphone |
Stereo electrect condenser microphone |
| Recording Media |
CF Card: 2 Slots, Movie files only SD Card: Still images, Custom Picture Data, Clip Metadata, Custom Settings |
| USB Terminal |
Mini-B USB 2.0 Hi-Speed |
| Video Terminal |
Component: Output only Composite: A/V terminal 3.5mm mini-jack, output only |
| Audio Terminal |
XLR 3-pin jack (2), Switchable between MIC/LINE, 3.5mm stereo mini-jack |
| HDMI Terminal |
Yes (Type A) |
| AV Mini Terminal/Headphone Terminal |
3.5mm stereo mini-jack |
| Remote Control Terminal |
Yes (compatible with LANC protocol) |
| Operating Temperature range |
0deg. - 40deg. C, 32deg. - 104deg. F, 85% relative humidity |
| Dimensions |
4.8" x 5.8" x 9.8" / 121 x 148 x 250 mm |
| Weight |
2.8 lbs / 1290 g |
