Vinten V3963-0002 Quattro-SL 4-Stage Pedestal f...
Vinten V3963-0002 Quattro-SL 4-Stage Pedestal V39630002
SKU: VOV39630002 MFR: V39630002
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Vinten Quattro-SL, a compact pedestal designed for multi-camera studio locations, is perfect for the increasing number of restricted sets and smaller studios around the world. The Quattro pedestal range is unique in its offering of a four stage telescopic column, allowing exceptional minimal height. The unique triangular column design offers unrivalled torsional stiffness, minimizing all unwanted rotational movement.
The low volume, low pressure pneumatic system combined with the new balance profile provides silky smooth, low effort elevation movement, allowing quiet and seamlessly developed shots. An optimized steering ring combined with low friction wheels allows confident tracking and reduced steering effort in any direction.
- Easily tracks through any 30" set restriction
- Alternative small 23.2" steering ring with tactile direction indicators provides a confident feel in any direction
- Low friction wheels greatly improve steering effort (<2Nm)
- Lightweight construction improves portability between studios without compromising stability
- Impressive 39.4" on-shot stroke
- Small base allows pedestals to work closer together
| Capacity |
176.4 lbs |
| Ground Clearance |
0.8" |
| On-Shot Stroke |
39.4" |
| Footprint |
31.8" x 29.4" |
| Wheel Diameter |
4.9" |
| Detachable Steering Ring Diameter |
29.1" |
| Minimum Height |
18.5" |
| Maximum Height |
57.8" |
| Tracking Width |
31.9" |
| Transit Doorway Width |
29.3" (with small steering ring)
32.3" (with large steering ring) |
| Weight (without trim weights) |
300.6 lbs |
| Total Trim Weights |
16.5 lbs |
| Warranty |
Vinten 1 year limited warranty |
