Sennheiser XSW 72 Wireless Instrument Microphone System, 548-572 MHz Frequency
Sennheiser XSW 72 Instrument Set Wireless Instrument Microphone System XSW72-A
SKU: SEXSW72A MFR: XSW72-A
What's Included
What's Included With This Item:
- Sennheiser SK 20 Bodypack Transmitter
- EM 10 True Diversity Receiver
- Cl 1 Instrument Cable (1/4")
- NT 2-3 Power Supply
- 2 x Rod Antennas
- 2 x AA Batteries
- Pouch
- Instruction Manual
- Sennheiser 2 Years Limited Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Sennheiser XSW 72 Instrument Set Wireless Instrument Microphone System (548-572 MHz frequency) delivers sound quality and performance in an affordable, easy to use package designed to keep musicians cable-free on stage. The XSW 72 Instrument Set features a true diversity receiver and bodypack transmitter with a 1/4" phone instrument cable for connecting guitars and other instruments.
The system operates on the 24 MHz UHF frequency band and features 960 tunable frequencies, 8 frequency banks and 12 coordinated channels per bank. True diversity reception greatly minimizes noise, interference and artifacts. Both the transmitter and receiver are capable of remote channel sync and the transmitter will operate for up to 10 hours on 2 AA batteries.
- Sennheiser SK 20 Bodypack Transmitter
- EM 10 True Diversity Receiver
- Cl 1 Instrument Cable (1/4")
- NT 2-3 Power Supply
- 2 x Rod Antennas
- 2 x AA Batteries
- Pouch
- Instruction Manual
- Sennheiser 2 Years Limited Warranty
- True Diversity reception for worry-free operation
- 24MHz switching bandwidth
- 960 available frequencies, tunable in 25kHz steps
- 8 frequency banks containing 12 coordinated channels each
- Powerful scan function identifies available channels within a bank
- Component synchronization at a distance with new "Remote Channel" sync
- Up to 10 hours of operation with (2) AA batteries
- Up to 250 feet of transmission range
- Illuminated audio mute button on transmitters
- Balanced (XLR) and unbalanced (1/4") outputs
| Receiver |
True diversity |
| Modulation |
Wideband FM |
| Sensitivity |
< 3 uV at 52dBarms S/N (at peak deviation) |
| Frequency Range |
548 - 572MHz |
| Switching Bandwidth |
24MHz |
| Adjacent Channel Crosstalk |
= 60dB |
| Intermodulation Distortion |
Intermodulation rejection = 50dB |
| Frequencies |
960, tunable in 25kHz steps
Frequency presets: 8 frequency banks, each with 12 coordinated factory-preset channels |
| Blocking |
= 65dB |
| Frequency Response |
60Hz-16kHz |
| Signal-to-Noise Ratio |
= 103dBa |
| THD |
= 1% |
| Temperature |
32 to 104deg. F (0 to +40deg. C) |
| Antenna Inputs |
2 BNC connectors, 50 ohm |
| Output Voltage |
XLR (balanced): +14dBu; 1/4" (unbalanced): +8dBu (at peak dev., 1kHz AF) |
| Power Supply |
12VDC nom. / 300mA |
| Dimensions |
13.39 x 13.58 x 3.35" / 34.01 x 34.49 x 8.50 cm (single) |
| Weight |
3.62 lbs / 1.64 kg (single) |
