| Type |
Compact Digital Camera |
| Effective Pixels |
14.1 million |
| Image Sensor |
1/2.3-in. type CCD |
| Total Pixels |
14.48 million (approx.) |
| Lens |
5x optical zoom, NIKKOR ED glass lens |
| Lens Focal Length |
6.3-31.5mm (angle of view equivalent to that of 35-175mm lens in 35mm [135] format) |
| Lens f/-number |
f/3.6-4.8 |
| Lens Construction |
13 elements in 10 groups |
| Digital Zoom |
Up to 4x (angle of view equivalent to that of approx. 700mm lens in 35mm [135] format) |
| Vibration Reduction |
Combination of image-sensor shift and electronic VR (still pictures)
Lens-shift (movies) |
| Autofocus (AF) |
Contrast-detect AF |
| Autofocus (AF) Focus range (from lens) |
[W]: 30cm (1ft.) to 8 (approx.)
[T]: 50cm (1ft. 8in.) to 8 (approx.)
Macro mode: 7 cm (2.8 in.) to 8 [W]
Unless otherwise stated, all figures are for a camera with a fully-charged Rechargeable Li-ion Battery EN-EL10 operated at an ambient temperature of 25°C (77 °F). |
| Autofocus (AF) Focus-area selection |
Face priority
Auto (9-area automatic selection)
Center
Manual (focus area can be selected using the touch panel)
Subject tracking |
| Monitor Size |
3.5 in. diagonal |
| Monitor Type |
Widescreen
OLED (touch panel)
Anti-reflection coating
5-level brightness adjustment |
| Monitor Resolution |
819,000-dots |
| Monitor Frame coverage (shooting mode) |
97% horizontal (Approx.)
97% vertical (Approx.)
(compared to actual picture) |
| Monitor Frame coverage (playback mode) |
100% horizontal (Approx.)
100% vertical (Approx.)
(compared to actual picture) |
| Storage Media |
SD memory card
SDHC memory card
SDXC memory card
79MB internal memory (approx.)
Unless otherwise stated, all figures are for a camera with a fully-charged Rechargeable Li-ion Battery EN-EL10 operated at an ambient temperature of 25°C (77°F). |
| Storage File System |
DCF
EXIF 2.2
DPOF compliant |
| Storage File formats |
Still pictures: JPEG
Sound files (Voice Memo): WAV
Movies: MOV (Video:MPEG-4 AVC/H.264, Audio: AAC stereo) |
| Movie Modes |
Movie file format: MPEG-4 AVC H.264
Audio file format: AAC stereo
HD: 1280 x 720p / 30fps
Standard TV: 640 x 480 / 30fps
Small Size: 320 x 240 / 30fps |
| Image Size (pixels) |
4352 x 3264 (14M)
3264 x 2448 (8M)
2592 x 1944 (5M)
2048 x 1536 (3M)
1024 x 768 (PC)
640 x 480 (VGA)
3968 x 2232 (16:9)
Unless otherwise stated, all figures are for a camera with a fully-charged Rechargeable Li-ion Battery EN-EL10 operated at an ambient temperature of 25 °C (77 °F). |
| ISO Sensitivity |
80
100
200
400
800
1600
3200
6400
Auto (auto gain ISO 80-800)
Fixed range auto (ISO 80-200, 80-400)
Unless otherwise stated, all figures are for a camera with a fully-charged Rechargeable Li-ion Battery EN-EL10 operated at an ambient temperature of 25 °C (77 °F). |
| Exposure Metering |
256-segment matrix, center-weighted (digital zoom less than 2X)
Spot (digital zoom 2X or more) |
| Exposure Control |
Programmed auto exposure with motion detection
Exposure compensation (-2.0 to +2.0 EV in steps of 1/3 EV) |
| Exposure Range (auto mode) |
[W]: 0.7 to 16.9 EV
[T]: 1.6 to 17.7 EV
(exposure values achieved with automatic ISO sensitivity adjustment converted to ISO 100 values) |
| Shutter |
Mechanical and charge-coupled electronic shutter |
| Shutter Speed |
1/1500-2 sec.
4 sec. (when scene mode is set to Fireworks show) |
| Aperture |
Electronically-controlled ND filter (-2.3 AV) insertion |
| Aperture Range |
2 steps (f/3.6 and f/8.1 [W]) |
| Self-timer |
Can be selected from 10 and 2 seconds duration |
| Built-in flash Range (approx.) |
(ISO sensitivity: Auto)
[W]: 0.5 to 4.0m (1 ft. 8 in. to 13 ft.)
[T]: 0.5 to 2.5m (1ft. 8in. to 8ft. 2in.) |
| Built-in Flash Control |
TTL auto flash with monitor preflashes |
| Interface |
Hi-speed USB |
| Interface Data transfer protocol |
MTP
PTP |
| Video Output |
NTSC
PAL |
| HDMI Output |
Can be selected from:
Auto
480p
720p
1080i |
| I/O terminal |
Audio/video (A/V) output
Digital I/O (USB)
HDMI mini connector (Type C) (HDMI output) |
| Supported Languages |
Arabic, Czech, Chinese (Simplified and Traditional), Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish |
| Power Sources |
One Rechargeable Li-ion Battery EN-EL10 (supplied)
AC Adapter EH-62D (available separately) |
| Charging Time |
3 hours (when using Charging AC Adapter EH-68P and when no charge remains)(Approx.) |
| Battery Type |
Rechargeable |
| Battery Life (shots per charge) |
Still pictures: Approx. 150 shots
Movies: Approx. 1 h 5 min (HD 720p (1280®720)) |
| Tripod Socket |
1/4 (ISO 1222) |
| Operating environment |
Temperature: 0 to 40°C (32 to 104°F)
Humidity: Less than 85% (no condensation) |
| Approx. Dimensions |
Height: 2.5 in. (62.6mm)
Width: 3.9 in. (98.8mm)
Depth: 0.7 in. (16.5mm)
(excluding projections) |
| Approx. Weight |
4.7 oz. (133g) (including battery and SD memory card) |
