Adesso Nuscan 3200U Optical Laser USB Barcode Scanner
Adesso Nuscan3200 Optical Laser Long Range USB Barcode Scanner NUSCAN3200U
SKU: ADNUSC3200U MFR: NUSCAN3200U
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The NuScan 3200 features the accuracy of laser compact, ergonomic and affordable design. It features technical advancements that eliminate internal vibrating mirrors and moving parts for better shock absorption, longevity and durability. Adesso NuScan barcode scanners combine high performance, accuracy and value. They offer best-in-class solutions for retail, point of sale, Office, Light Industrial, Warehouse, Libraries, Medical, Legal office, Government, marketing and any repetitive application where time and precision are critical factors in helping businesses streamline their workflow. The USB version is compatible with MAC OSX and Windows.
- Better Shock-Proofing and Durability: New patented Optical Laser Technology integrates a fixed optical lens; instead of traditional vibrating & rotating mirrors, which are very fragile. this new technology improves shock absorption and enhances durability
- Superior Scanning Performance: The NuScan 3200 supports scan fields as wide as 6 inches and 16 inches deep, scanning at a rate of 80 scans per second
- Less Harmful to your Eyes: By using a fixed expanding laser light, the NuScan 3200 is less harmful to your eyes than traditional barcode scanners
- Low Power Consumption: Running on an Operating Current of only 80mA at 5v DC, the NuScan 3200 uses approximately 35% less energy than traditional Laser barcode scanners
- Less Electromagnetic Interference: The Patented Optical Laser Technology reduces electromagnetic interference, reducing the chance of signals getting skipped and misread
| Light Source |
650nm Laser Diode |
| Depth of field |
Up to 16 Inches |
| Width of field |
Up to 6 inches |
| Scan Speed |
80 scans per second |
| Best Resolution |
0.1mm (4mils) -Code 39 |
| Print Contrast |
45% or more |
| Indicators (LED) |
Two-Color Blue & Red LED & Beeper |
| Interface |
PS/2 or USB |
| Cable |
6 ft |
| Input Voltage |
5VDC ± 0.5v |
| Operating Standby |
25 mA at 5v |
| Operating Current |
80 mA at 5v |
| Regulation |
FCC Class A & CE |
| Operating Temperature |
0deg.C - 50deg.C (32deg.F - 122deg.F) |
| Storage Temperature |
-20deg.C - 60deg.°C (-4deg.F - 140deg.F) |
| Humidity-Storage |
5% - 95% (non-condensing) |
| Light Levels |
Max. 80,000 LUX |
| Shock |
Designed to withstand 1.5 m drops |
| Dimensions (H x D xW) |
6.10 in x 3.14 in x 2.55 in / 15.49 x 7.98 x 7.98 cm |
| Weight |
150g +/- 5g / 0.33lbs +/-0.01 lbs (Cable not included) |
