| Image Capture Device Type |
12.1 Megapixel, 1/1.7-inch CMOS |
| Total Pixels |
Approx. 13.3 Megapixels |
| Effective Pixels |
Approx. 12.1 Megapixels |
| Focal Length |
5.2 (W) - 26.0 (T) mm (35mm film equivalent: 24-120mm) |
| Focusing Range |
Normal: 2.0 in. (5cm) - infinity (W), 12 in. (30cm) - infinity (T) Auto: 1.2 in. (3cm) - infinity (W), 12 in. (30cm) - infinity (T) Macro AF: 1.2 in. - 1.6 ft. (3-50cm) (W), 12 in. - 1.6 ft. (30-50cm) (T) |
| Autofocus System |
TTL Autofocus, Manual Focus |
| LCD Monitor |
3.0-inch TFT Color LCD with Touch-screen panel with wide viewing angle |
| LCD Pixels |
Approx. 461,000 dots |
| LCD Coverage |
Approx. 100% |
| Maximum Aperture |
f/2.0 (W) - f/5.9 (T) |
| Shutter Speed |
1-1/2000 sec. 15-1/2000 sec. (in Tv and M modes) |
| Sensitivity |
Auto, ISO 80-12800 |
| Light Metering Method |
Evaluative, Center-weighted average, Spot |
| Exposure Control Method |
Manual Exposure, Program Shift, Safety Shift, AE Lock |
| Exposure Compensation |
Still Images: ±3 stops in 1/3-stop increments Videos: ±3 stops in 1/3-stop increments (not available during shooting) |
| White Balance Control |
Auto, Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Flash, Underwater, Custom 1, Custom 2 |
| Built-in Flash |
Auto, Flash On, Slow Synchro, Flash Off |
| Flash Range |
1.6 ft. - 23 ft. (W), 1.6 - 7.5 ft. (T) (50cm - 7m (W), (50cm - 2.3m (T)) |
| Recycling Time |
10 sec. or less (battery voltage: 3.7 V) |
| Flash Exposure Compensation |
+/-2 stops in 1/3-stop increments |
| Shooting Modes |
C, M, Av, TV, P, Auto, Movie Digest, SCN, Creative Filters, Movie |
| Photo Effects |
My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red, Custom Color |
| Self Timer |
Approx. 10-sec. delay/approx. 2-sec. delay/custom |
| Continuous Shooting |
1) Normal: Approx. 2.1 shots/sec. (in P mode) Approx. 10 shots/sec. (in High-Speed Burst HQ) 2) AF: Approx. 0.9 shots/sec. (in P mode) Approx. 4.4 shots/sec. (in High-Speed Burst HQ) 3) LV: Approx. 0.9 shots/sec. (in P mode) |
| Storage Media |
SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| File Format |
Design rule for Camera File system, DPOF (Version 1.1) compliant |
| Image Recording Format |
Superfine / Fine |
| JPEG Compression Mode |
Still Image: Exif. 2.3 (JPEG) Video: MOV (Image: H.264; Audio: Linear PCM (Stereo)) |
| No. of Recording Pixels: Still Images 1 |
16:9 - Large: 4000 x 2248; Medium 1: 2816 x 1584; Medium 2: 1920 x 1080; Small: 640 x 360; RAW: 4000 x 2248 3:2 - Large: 4000 x 2664; Medium 1: 2816 x 1880; Medium 2: 1600 x 1064; Small: 640 x 424; RAW: 4000 x 2664 4:3 - Large: 4000 x 3000; Medium 1: 2816 x 2112; Medium 2: 1600 x 1200; Small: 640 x 480; Raw: 4000 x 3000 |
| No. of Recording Pixels: Still Images 2 |
1:1 - Large: 2992 x 2992; Medium 1: 2112 x 2112; Medium 2: 1200 x 1200; Small: 480 x 480; RAW: 2992 x 2992 4:5 - Large: 2400 x 3000; Medium 1: 1696 x 2112; Medium 2: 960 x 1200; Small: 384 x 480; RAW: 2400 x 3000 |
| No. of Recording Pixels: Videos |
Full HD 1920 x 1080: 24 fps (23.976) HD 1280 x 720: 30 fps (29.97) iFrame Movie HD 1280 x 720: 30 fps (29.97) Movie Digest HD 1280 x 720: 30 fps (29.97) Miniature Effect HD 1280 x 720: 6 fps / 3 fps / 1.5 fps Miniature Effect 640 x 480: 6 fps / 3 fps / 1.5 fps Super Slow Motion Movie 640 x 480: 120 fps Super Slow Motion Movie 320 x 240: 240 fps 640 x 480: 30 fps (29.97) |
| Playback Modes File: Stills & Videos |
Auto Rotate (Automatic vertical/horizontal detection), Index Continuous Display, Image Advance (Operation Tools, Transition Effects, Scroll Display), Rotate, Favorites, My Category, Smart Shuffle, Group Playback, Movie Digest, Slideshow (Playback Interval, Repeat, Effect, Playlist) |
| Playback Modes File: Still Images |
Single, Index, Magnification (2-10x), Switch to other images while zoomed, Information Display, Red-eye Correction, i-Contrast, Photobook Setup, Trimming, Resize, My Colors, Face ID info, Focus Check, Histogram, RGB Histogram, Location Information, Overexposure Warning |
| Playback Modes File: Videos |
Normal Playback, Slow Motion, Skip Backward, Previous Frame, Next Frame, Skip Forward, Erase chapters, Editing |
| Erase Modes |
Select Image, Select Range, Select All Images |
| Video Out |
NTSC/PAL (dedicated connector (female) with unified type of digital, audio and video) Mini-HDMI connector |
| Audio Out |
Stereo (dedicated connector (female) with unified type of digital, audio and video) |
| Other Interface |
SD memory card slot; direct connection to Canon SELPHY, PIXMA Photo Printers & PictBridge compatible printers |
| Power Source |
Battery Pack NB-5L |
| Shooting Capacity |
Still Image: approx. 200 shots |
| Playback Time |
Approx. 4 hours |
| Operating Temperature |
32-104deg.F/0-40deg.C |
| Operating Humidity |
10-90% |
| Dimensions (W x H x D) |
3.89 x 2.32 x 1.06 in. / 98.8 x 59.0 x 26.9mm |
| Weight |
6.98 oz. / 198g (CIPA standard) 6.10 oz. / 173g (camera only) |
