| Amplifier: Power Output |
Front L/R:
105W + 105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
135W + 135W (6 ohms, 1 kHz, THD 0.7%)
Center:
105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
135W (6 ohms, 1 kHz, THD 0.7%)
Surround L/R:
105W + 105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
135W + 135W (6 ohms, 1 kHz, THD 0.7%)
Surround back L/R:
105W + 105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
135W + 135W (6 ohms, 1 kHz, THD 0.7%) |
| Amplifier: Input Sensitivity |
200 mV / 47 kohms |
| Amplifier: Frequency Response |
10 Hz - 100 kHz - +1, -3dB (DIRECT mode) |
| Amplifier: Signal to Noise Ratio |
100 dB (IHF-A weighted, DIRECT mode) |
| Amplifier: No. of Channels |
7.2 |
| Audio Processing: Dolby TrueHD |
Yes |
| Audio Processing: Dolby Digital Plus |
Yes |
| Audio Processing: Dolby Pro Logic IIz |
Yes |
| Audio Processing: DTS-HD Master Audio |
Yes |
| Audio Processing: DTS-HD HR Audio |
Yes |
| Audio Processing: DTS ES |
Yes, Matrix 6.1/Discrete 6.1 |
| Audio Processing: DTS Neo:6 |
Yes |
| Audio Processing: DTS 96/24 |
Yes |
| Audio Processing: THX Surround EX |
No |
| Audio Processing: THX Certified |
No |
| Speaker Selector |
Yes |
| Multi Room/Source |
Yes/Yes |
| AM/FM Tuner |
Yes |
| Remote Control |
Yes |
| Inputs |
HDMI (front 1) x 6
Component video x 2
Composite video (front 1) x 4
Analog audio (front 1) x 6
Digital optical audio x 2
Digital coaxial audio x 2 |
| Outputs |
HDMI x 2
Component video x 1
Composite video x 2
Subwoofer preouts x 2
Audio preout (L/R) x 1
Audio preout (zone 2 L/R)
Phones x 1 |
| Other Ports |
Ethernet x 1
USB port x 1
Setup mic jack x 1
FM tuner antenna x 1
Remote control (in/out) x 1/x 1
RC-232C x 1
DC12V 150 mA max trigger out x 1 |
| Video Input Conversion |
4K upscaling |
| Power Requirements |
120 VAC, 60 Hz |
| Power Consumption |
600W (standby 0.1W, CEC standby 0.5W) |
| Dimensions (W x H x D) |
17-3/32 x 6-37/64 x 17-3/32" (434 x 166 x 434 mm) |
| Weight |
24 lbs (10.8 kg) |
