| Type of System |
Rack/Table Top Mountable UHF Diversity Wireless Handheld System |
| RF Carrier Frequency Range |
Frequency G3 / 470 - 505 MHz |
| Approx. Working Range |
300 Feet (100m) |
| Overall Frequency Response |
25Hz - 15kHz, (±2dB) |
| Signal-to-Noise Ratio |
Greater Than 90dB |
| No. Of Channels |
Over 1400 User Selectable Frequencies |
| No. Of Simultaneous Systems |
Up to 20 |
| Type of Receiver |
ULXS4 Rack/Table-Top Mount UHF Standard Diversity Receiver |
| Receiver: Type of Outputs |
Balanced XLR - 22 Ohms, 1 = Ground, 2 = Hot, 3 = Cold Unbalanced 1/4" Phone Jack - 3k Ohms, Tip = Hot, Ring/Sleeve = Gnd
(Both Outputs Feature: Voltage, Current and Phantom Power Protection) |
| Receiver: Headphone Monitoring |
No |
| Receiver: Power Requirements |
14 - 18VDC (negative ground), 550mA
External Power Supply - PS40, Included |
| Receiver: Display |
Yes, Power On Indicator, Diversity Signal Indicators and Audio Peak Indicator, Channel, Group, Transmitter Low Battery Warning. |
| Receiver: Mounting Options |
Rack / Table Top Mount 1/2 Rack Space |
| Receiver: Antenna Type |
Internal |
| Type of Transmitter |
ULX2/BETA 87A Handheld UHF Transmitter |
| Transmitter: Type of Input Connector |
Microphone Element is Attached (Screwed On) to Transmitter |
| Transmitter: Type of Microphone |
BETA87A Dynamic Microphone Head |
| Transmitter: Polar Pattern |
Supercardioid |
| Transmitter: Interchangeable Mic Heads |
No |
| Transmitter: Battery Type/Approx. Life |
9V Lithium Battery / 21 Hours (Recommended)
9V Alkaline Battery / 8 - 9 Hours (Recommended) |
| Transmitter: Mute Switch |
Yes |
| Transmitter: Level Control |
Yes, 25dB Gain Adjustment Range |
| Transmitter: Antenna Type |
Remotable 1/2 Wave, Rear Mounted |
| Transmitter: Display |
Power On/Off Indicator, 3-Segment Low Battery Indicator, Channel and Group, Peak Icon (Input Overload Warning) |
| Dimensions |
Receiver (HxWxD): 1.72 x 8.56 x 6.88" (43 x 217 x 174mm)
Transmitter (L x Dia): 8.5 x 2" (216 x 51mm) |
| Weight |
Receiver: 10.4 oz. (294g)
Transmitter: 2 lbs. 7 oz. (1105 g) |
