| Standards |
IEEE 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) |
| Ports |
LAN Fast Ethernet auto sensing, DC jack 10BASE-T/100BASE-TX Ethernet, 12V DC power with support for 802.3af PoE |
| Switch |
Power button (on/off) |
| Buttons |
Power (on/off) push button; Reset button |
| Cabling type |
Category 5e or better |
| Antennas |
Internal antennas optimized for wall, ceiling, or desktop placement |
| LEDs |
Power, WLAN, LAN |
| Operating system |
Linux |
| Power supply |
External 12V 0.5A DC power jack (Energy Star 2.0 compliant with Efficiency Level 5) and 802.3af PoE |
| Lock slot |
Slot for Kensington lock |
| VLAN support |
Yes |
| Number of VLANs |
1 management VLAN plus 4 VLANs for SSID |
| 802.1X supplicant |
Yes |
| SSID to VLAN mapping |
Yes |
| Auto channel selection |
Yes |
| Spanning tree |
Yes |
| Load balancing |
Yes |
| IPv6 |
Yes IPv6 host support IPv6 RADIUS, syslog, Network Time Protocol (NTP), etc. |
| Layer 2 |
802.1Q-based VLANS, 4 active VLANS plus 1 management VLAN |
| WPA/WPA2/WEP |
Yes, including Enterprise authentication |
| Access control |
Yes, management access control list (ACL) plus MAC ACL |
| Secure management |
HTTPS |
| Wi-Fi Protected Setup (WPS) |
Yes (soft WPS, no hardware push button) |
| SSID broadcast |
Yes |
| Rogue access point detection |
Yes |
| Multiple mounting options |
Desktop installation; mounting bracket included for easy ceiling or wall mounting |
| Physical security lock |
Kensington lock slot |
| Quality of service (QoS) |
Wi-Fi Multimedia & Traffic Specification (WMM TSPEC) |
| Wireless throughput |
Up to 300 Mbps data rate (real world throughput will vary) |
| Recommended user support |
Up to 16 connected users, or 10 active users. |
| Web user interface |
Built-in web user interface for easy browser-based configuration (HTTP/HTTPS) |
| Management protocols |
Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour |
| Remote management |
Yes |
| Event logging |
Local, remote syslog, email alerts |
| Network diagnostics |
Logging and packet capture |
| Web firmware upgrade |
Firmware upgradable through web browser, imported/exported configuration file |
| DHCP |
Dynamic Host Configuration Protocol: DHCP client |
| IPv6 host |
Yes |
| HTTP redirect |
Yes |
| Frequency |
Single-band 2.4GHz |
| Radio and modulation type |
Single radio, orthogonal frequency division multiplexing(OFDM) |
| WLAN |
802.11n |
| Operating channels |
1 to 13 (depending on country) Channels 1 through 11 (FCC) Channels 1 through 13 (ETSI) |
| Wireless isolation |
Wireless isolation between clients |
| External antennas |
No |
| Internal antennas |
Internal fixed PIFA antennas |
| Antenna gain in dBi |
2dBi each antenna |
| Transmitted output power |
802.11b@11Mbps: 17dBm 802.11g@54Mbps: 13 dBm 802.11n@HT20HT40, MCS15: 13dBm |
| Receiver sensitivity |
802.11b: 11Mbps@-86dBm 802.11g: 54Mbps@-71dBm 802.11n: 300Mbps@-64dBm |
| Wireless distribution system (WDS) |
Yes |
| Roaming |
Yes |
| Multiple SSIDs |
4 |
| Wireless VLAN map |
Yes |
| WLAN security |
Yes |
| Wi-Fi Multimedia (WMM) |
Yes, with unscheduled automatic power save |
| Access point |
Access Point mode, WDS bridging, Client Bridge mode |
| Power |
12V,0.5ADC input and IEEE802.3af compliant PoE |
| Certifications |
FCC class B, CE, IC, Wi-Fi |
| Operating temperature |
0deg. to 40deg.C (32deg. to 104deg.F) |
| Storage temperature |
-20deg. to 70deg.C (-4deg. to 158deg.F) |
| Operating humidity |
10% to 85% noncondensing |
| Storage humidity |
5% to 90% noncondensing |
| Minimum Requirements |
802.11b, 802.11g, 802.11n wireless adapter with TCP/IP protocol installed per PC Switch/router with PoE support or PoE injector when used with PoE Web-based configuration: Java-enabled web browser |
| Dimensions (W x D x H) |
4.89 x 4.89 x 1.38" (124.21 x 124.21 x 35.1 mm) |
| Weight |
0.37 lbs (0.168 kg) |
