| Type of System |
Rack/Table Top Mountable UHF Diversity Wireless Handheld System |
| RF Carrier Frequency Range |
554.000 to 865.000MHz |
| Approx. Working Range |
300 Feet (100m) |
| Overall Frequency Response |
25Hz - 15kHz, (±2dB) |
| Signal-to-Noise Ratio |
Greater Than 90dB |
| No. Of Channels |
Over 1400 User Selectable Frequencies |
| No. Of Simultaneous Systems |
Up to 20 |
| Type of Receiver |
ULXP4 Professional Rack/Table-Top Mount Receiver |
| Receiver: Type of Outputs |
Balanced XLR - 22 Ohms, 1 = Ground, 2 = Hot, 3 = Cold Unbalanced 1/4" Phone Jack - 3k Ohms, Tip = Hot, Ring/Sleeve = Gnd(Both Outputs Feature: Voltage, Current and Phantom Power Protection) |
| Receiver: Headphone Monitoring |
No |
| Receiver: Power Requirements |
14 - 18VDC (negative ground), 550mA
External Power Supply - PS40, Included |
| Receiver: Display |
Yes, Power On Indicator, Diversity Signal Indicators and Audio Peak Indicator, Channel, Group, Transmitter Low Battery Warning. |
| Receiver: Mounting Options |
Rack / Table Top Mount 1/2 Rack Space |
| Receiver: Antenna Type |
Internal |
| Bodypack Transmitter: Input Connector |
TAF4 4-Pin Mini Connector |
| Bodypack: Interchangeable Mic Heads |
Yes, Use any of the Shure Lavalier, Headset, Instrument Microphones, or Guitar/Bass/XLR Adapter Cables that terminate to a Mini 4-pin TA4F Connector. |
| Bodypack Transmitter: Battery Life |
Non-Rechargeable Type:
9V Lithium Battery / 21 Hours (Recommended)
9V Alkaline Battery / 8 - 9 Hours (Recommended) |
| Bodypack Transmitter: Mute Switch |
Yes |
| Bodypack Transmitter: Level Control |
Yes, 25dB Gain Adjustment Range |
| Bodypack Transmitter: Antenna Type |
Remotable 1/2 Wave, Rear Mounted |
| Bodypack Transmitter: Display |
Power On/Off Indicator, 3-Segment Low Battery Indicator, Channel and Group, Peak Icon (Input Overload Warning) |
| Handheld Transmitter: Input Connector |
Microphone Element is Attached (Screwed On) to Transmitter |
| Handheld Transmitter: Microphone Type |
BETA58 Dynamic Microphone Head |
| Handheld Transmitter: Polar Pattern |
Cardioid |
| Handheld Transmitter: Battery Life |
Non-Rechargeable Type:
9V Lithium Battery / 21 Hours (Recommended)
9V Alkaline Battery / 8 - 9 Hours (Recommended) |
| Handheld Transmitter: Mute Switch |
Yes |
| Handheld Transmitter: Level Control |
Yes, 25dB Gain Adjustment Range |
| Handheld Transmitter: Antenna Type |
Wire Type |
| Handheld Transmitter: Display |
Power On/Off Indicator, 3-Segment Low Battery Indicator, Channel and Group, Peak Icon (Input Overload Warning) |
| Dimensions ( HxWxD) |
Receiver: 1.72 x 8.56 x 6.88" (43 x 217 x 174mm) |
| Weight |
Receiver: 2.8 oz. (79 g) without Battery
Bodypack UHF Transmitter: 10.4 oz. (294 g)
Handheld UHF Transmitter: 2 lbs., 7 oz. (1105 g) |
