| Inputs |
Analog: 8 x XLR Microphone (front panel)
2 x 1/4" TRS phone Balanced Line (front panel)
4 x 1/4" TRS phone Balanced Line (rear panel)
Digital: 1 x RCA coaxial S/PDIF, 75O |
| Outputs |
Analog: 6 x 1/4" TRS phone Balanced Line (rear panel)
1 x 1/4" TRS phone Headphone (front panel)
Digital: 1 x RCA coaxial S/PDIF, 75O (switchable to AES/EBU) |
| MIDI |
2 x 5-pin DIN MIDI In/Out |
| Connectivity |
USB 2.0 |
| Sample Rate |
44.1, 48, 88.2 and 96kHz |
| Input Level |
Microphone:
Nominal: -2dBu (0.615Vrms)
Minimum: -58dBu (0.0009Vrms)
Maximum: +14dBu (3.882Vrms)
Line 9-10:
Nominal: +4dBu (1.228Vrms)
Minimum: -42dBu (0.0062Vrms)
Maximum: +20dBu (7.746Vrms)
Line 11-12:
Nominal: -10dBV (0.3162Vrms)/+4dBu (1.228Vrms)
Maximum: +6dBV (1.995Vrms)/+20dBu (7.746Vrms)
Guitar:
Nominal: -6dBV (0.501Vrms)
Minimum: -52dBV (0.615Vrms)
Maximum: +10dBV (3.162Vrms) |
| Input Impedance |
MIC IN 1-8: 2.2kOhm
Guitar 9-10: 700kOhm
LINE IN 9-10: 700kOhm
LINE IN 11-14: 10 kOhm
Coaxial (DIGITAL IN) terminal: 75Ohm |
| Gain Range |
Microphone: 55dB |
| Output Level |
Line 1-4:
Nominal: +4dBu (1.228Vrms)
Maximum: +24dBu (12.227Vrms)
Monitor:
Nominal: +4dBu (1.228Vrms)
Maximum: +24dBu (12.227Vrms)
Headphone:
Maximum: 50mW + 50mW (1kHz, 1%, 32O load) |
| Output Impedance |
Line Out 1-4: 100 ohms
Monitor L/R: 100 ohms
Coaxial (DIGITAL OUT) terminal: 75Ohms |
| Dynamic Range |
Output: 115dB RMS unweighted, 118dBA |
| THD |
Less than 0.01%, mic in->line out, gain at minimum |
| Signal to Noise Ratio |
96dB or more, mic in->line out, gain at minimum, 44.1kHz |
| Frequency Response |
20Hz-20kHz, +1/-1dB (44.1/48kHz)
20Hz-40kHz, +1/-3dB (88.2/96kHz)
(MIC IN-Line OUT, Gain knob set to minimum, JEITA) |
| Power Supply |
AC Input: External PSU, 100-240VAC, 50/60Hz, 1.0A
DC Output: +12V, 2.0A |
| Power Consumption |
7.2W |
| System Requirements |
Mac:
PowerPC G4 or Intel processor
OS X 10.5.8 (Intel and PPC), OS X 10.6 (Intel)
1GB RAM
USB 2.0 port
PC: Pentium IV 1.4GHz or faster, AMD Athlon 1.4GHz or faster
Windows XP SP2 (32- or 64-bit), Vista SP2 (32- or 64-bit), Windows 7 (32- and 64-bit)
512MB RAM for Windows XP and Vista, 1GB for Windows XP and Vista (64-bit), Windows 7 (32-bit)
2GB RAM for Windows 7 (64-bit)
USB 2.0 port |
| Operating Temperature |
41 to 95 Deg. F (5 to 35 Deg. C) |
| Dimensions |
19 x 11.02 x 1.73" (483 x 280 x 44mm) |
| Weight |
6.8 lb (3.1kg) |
