| Flash energy |
1200 J |
| F-stop at 2 m (6-1/2 ft.)100 ISO |
Litos lamp with Litos reflector: 32-1/10
Litos lamp with P70 reflector: 45-8/10
Pulso G lamp with P70 reflector: 45-7/10 |
| Flash duration t 0.1 (t 0.5) at 230 V |
Litos lamp: 1200 J: 1/180 s (1/600 s), 600 J: 1/360 s (1/1200 s)
Pulso G/Unilite lamp: 1200 J: 1/100 s (1/300 s), 600 J: 1/200 s (1/600 s) |
| Charging time (100% of selected energy) |
0.4 - 1.5 s (200-240 V)
0.4 - 1.5 s (110-120 V)
0.5 - 1.9 s (100 V) 900 J |
| Ready display |
Visual and audible (can be switched off), signals when 100% of selected energy is reached |
| Number of lamp outlets |
3 |
| Power distribution |
Free asymmetry up to 5 f-stops in whole and 1/10 f-stop intervals |
| Control range of flash energy |
6.5 f-stops or 13 J to 1200 J (1 lamp) with activated symmetry switch |
| Modeling light |
100 - 240 V, halogen max. 3x300 W (Litos)
200 - 240 V, halogen max. 3x650 W (Pulso G/Unilite)
Proportional to flash energy, full power |
| Flash release |
Manual release button, photocell, RFS 2 receiver (radio frequency), sync cable |
| Radio (2.4 GHz) |
99 workstations, 99 unit addresses, 40 frequency channels |
| No. of sync sockets |
1 |
| Dimensions (L x W x H) |
203 x 148 x 218 mm (8 x 5.8 x 8.6") excl. handle |
| Weight |
4.6 kg (10.1 lbs) |
