Chief PIWRFU 15" Large Low-Profile In-Wall Swing Arm Mount
Chief
Chief PIWRFU 15" Large Low-Profile In-Wall Swing Arm Mount PIWRFUB
SKU: CHPIWRFUB MFR: PIWRFUB
Usually ships in 3-5 days
What's Included
What's Included With This Item:
- Chief PIWRFU 15" Large Low-Profile In-Wall Swing Arm Mount
- Upper and Lower Mounting Rails
- 4 x Spacers
- 4 x End Caps
- Upper and Lower Channel Covers
- 2 x Trim Pieces
- 4 x Lag Screws
- 4 x Washers
- 4 x Flanged Nuts
- 8 x Cable Tie Clips
- 2 x Cable Covers
- Chief Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The state-of-the-art Chief PIWRFU is a fully integrated, pre-assembled swing arm, fitting flush inside the wall with a low-profile finish. Designed for 42-71" flat panel displays up to 200 lbs, the PIWRFUB allows perfect TV placement during installation without cutting studs or having to retrofit existing wall structures. Simply cut out the drywall at the desired wall location and install the in-wall box. In addition, installation is made easier with built-in lateral shift and height adjustment.
Integrated cable management and a trim kit are provided for an aesthetic and low-profile finish of less than 2". Users have increased positioning flexibility of their display with wide viewing angles. Optimal viewing is achieved with 40deg. of left/right swivel, up to 15" (381mm) of extension, fingertip tilt and ultra smooth movement. The PIWRFU includes a universal interface bracket making it compatible with hundreds of flat panel displays.
- Chief PIWRFU 15" Large Low-Profile In-Wall Swing Arm Mount
- Upper and Lower Mounting Rails
- 4 x Spacers
- 4 x End Caps
- Upper and Lower Channel Covers
- 2 x Trim Pieces
- 4 x Lag Screws
- 4 x Washers
- 4 x Flanged Nuts
- 8 x Cable Tie Clips
- 2 x Cable Covers
- Chief Warranty
- Limitless centering on the wall between 16" center studs without cutting studs
- Low profile design ensures the mount remains concealed behind the flat panel
- Centris Technology uses the center of gravity to achieve smooth, fingertip tilt
- ClickConnect Technology provides an audible click to confirm the flat panel is locked in place
- Easy connect/disconnect with no tools needed
- Screen can be installed in portrait or landscape orientation ( PAC400 accessory can be used to rotate without removing the screen)
- Integrated cable management
| Compatibility |
Large Flat Panels from 42 to 65" |
| Certifications |
UL Listed |
| Lateral Shift |
5" (127 mm) |
| Manual Height Adjustment |
1" (25.4 mm) |
| Maximum Extension |
15" (381mm) |
| Minimum Depth |
1.7" (43.2 mm) |
| Mounting Pattern Compatibility |
200 x 200mm - 862 x 517mm (Universal Versions) |
| Orientation |
Landscape, Portrait |
| Pivot (numerical value) |
+/- 40.3deg.(depending on screen width) |
| Post-Installation Leveling (Roll) |
Yes |
| Solution Type |
Universal |
| Tilt |
+ 2deg., - 15deg. |
| Typical Screen Sizes |
42 - 71" (1066.8 - 1803.4 mm) |
| Wall Stud Compatibility |
16" (406.4 mm) |
| Load Capacity |
200 lbs (90.7kg) |
| Dimensions (H x W x D) |
22.8 x 20.4 x 5.5" (579.12 x 518.16 x 139.7 mm) |
