| Type of System |
Handheld / Body-Pack Combo UHF, Rackmount Type Receiver |
| RF Carrier Frequency Range |
X1/944-952MHz |
| Approx. Working Range |
500' (150 m) typical conditions |
| Overall Frequency Response |
40Hz to 18kHz +/- 1dB |
| Signal-to-Noise Ratio |
Ultimate Quieting (ref. 45kHz deviation) <100dB, A-weighted |
| No of Channels |
2400 Selectable Frequencies Across 60MHz Bandwidth |
| No of Simultaneous Systems |
Up to 60 Preset Compatible Systems/Band (140 w/Multiple Bands, Region Dependent) |
| Receiver: Type of Outputs |
XLR 3-pin: Mic / Line Switchable, Balanced Low-Z with Ground Lift Switch 1/4" Phone: 200 ohms USB: Computer Interface RJ-45: Ethernet Network Interface |
| Receiver: Headphone Monitoring |
1/4" Phone with level control dial |
| Receiver: Power Requirements |
100 to 240VAC, 50/60Hz 0.8 Amps max. |
| Receiver: Display |
Backlit LCD: Group and Channel, Frequency, Automatic Transmitter Sync, Receiver name, Output Level, Squelch, Receiver Lock, LCD View, Contrast, ToneKey, Network Parameters |
| Receiver: Mounting Options |
Rack Mount Hardware (Included) |
| Receiver: Antenna Type |
Flexible Antenna |
| UR1 Transmitter: Type of Input Connector |
TA4-Male (mini 4-pin male connection) |
| UR1 Transmitter: Mic Heads |
Compatible with lavalier and head worn microphones with TA4-Male connectors |
| UR1 Transmitter: Battery Type/Life |
1.5V AA Alkaline Batteries x2 9.5 hours (low power) 6 hour (high power) |
| UR1 Transmitter: Level Control |
Gain: -10dB to +20dB |
| UR1 Transmitter: Antenna Type |
Two band dependent antennas |
| UR1 Transmitter: Display |
Backlit LCD |
| UR2 Transmitter: Polar Pattern |
Supercardioid |
| UR2 Transmitter: Mic Heads |
No |
| UR2 Transmitter: Battery Type/Life |
1.5V AA Alkaline Batteries x2 9.5 hours (low power) 6 hour (high power) |
| UR2 Transmitter: Level Control |
Gain: -10dB to +20dB |
| UR2 Transmitter: Antenna Type |
Flexible Antenna |
| UR2 Transmitter: Display |
Backlit LCD |
| Dimensions |
Receiver: 1.72 x 19 x 14.39" (43.6 x 482.6 x 365.5mm) UR1 Transmitter: 10.27 x 2" (260.8 x 50.8mm) UR2 Transmitter: 2.38 x 3.84 x 0.66" (60.4 x 97.5 x 16.7mm) |
| Weight |
Receiver:11 lbs (5kg) UR1 Transmitter: 12.6 oz (357.2g) UR2 Transmitter: 11 lbs (5kg) |
