Marshall 17" LCD Desktop Monitor with Dual HD-SDI Input
Marshall 17" LCD Desktop Monitor V-LCD17H-2HD-DT
SKU: MARVLCD17H2H MFR: V-LCD17H-2HD-DT
What's Included
What's Included With This Item:
- Marshall 17" LCD Desktop Monitor
- Power Supply
- Desktop Stand
- Marshall Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Marshall 17" LCD Desktop Monitor with Dual HD-SDI Input is a multi-featured desktop display intended for low-budget broadcast productions. It is designed thin and robust and is equipped with two HD-SDI inputs, one such output and a tally input. A desktop stand comes included.
Resolution is at 1400 x 900, contrast ratio at 600:1 and aspect ratio at 16:10. Brightness is 250 nits. The rich features of the monitor help with calibration, exposure and other functions and consist of Status Display, False Color Filter, Markers, Freeze Function, Color Temperature Presets, RGB Gain/Bias Adjust, Pixel-to-Pixel, Blue Gun and Hard Tally. The False Color feature helps set exposure by displaying overexposed areas in red, underexposed areas in deep-blue to dark-blue and properly exposed areas in elements of green and pink.
- Marshall 17" LCD Desktop Monitor
- Power Supply
- Desktop Stand
- Marshall Warranty
- Thin and robust 17" display with a 16:10 aspect ratio
- Equipped with 2 HD-SDI ins/1 out, a tally in and a desktop stand
- Features 1400 x 900 resolution, 600:1 contrast and 250 nits of brightness
- User-definable buttons are available for programming the monitor's functions into
- Functions include False Color, RGB Gain/Bias Adjust, Pixel-to-Pixel, Blue Gun and Hard Tally
| Connections |
Two HD-SDI inputs / one HD-SDI output (cold swap only)
15-pin tally input |
| Viewing Area |
17" diagonally (43 cm) |
| Resolution |
1400 x 900 |
| Aspect Ratio |
16:10 |
| Pixel Pitch |
0.255 x 0.255 mm (0.010 x 0.010") |
| Brightness |
250 cd/m2 |
| Contrast Ratio |
600:1 |
| Dimensions |
18.9 x 10.45 x 1.4" (48 x 26.5 x 3.5 cm) |
| Weight |
8.8lbs (4 kg) |
