| Printer Type |
5-Color 36-inch Printer |
| Number of Nozzles |
Total: 15,360
MBK: 5,120 nozzles
C, M, Y, BK: 2,560 nozzles each |
| Nozzle Pitch |
1,200 dpi
Non-firing nozzle detection and compensation |
| Print Resolution (Up to) |
2,400 x 1,200 dpi (Max) |
| OS Compatibility |
Windows (2000/XP/Vista 32/64bit)
Mac (OS10) |
| Standard Interface |
USB 2.0 High-Speed
10/100/1000 Base-T/TX |
| Ink Droplet Size |
4 picoliter |
| Ink Capacity |
130ml per color |
| Ink Types |
Dye/Pigment Reactive Ink |
| Color Set |
Dye: Cyan, Magenta, Yellow, Black
Pigment: Matte Black (two channels) |
| Buffer/Ram |
256 MB |
| Media Width |
Cut Sheet - 8"- 36" (203.2mm - 914mm)
Roll Feed - 10" - 36" (254mm - 914mm) |
| Media Thickness |
0.07-0.8mm (2.8-31.4mil) |
| Maximum Roll Print Length |
Roll Feed - 59' (18 meters)
Cut Sheet - 63" (1.6 meters) |
| Maximum Media Roll Diameter |
5.9" (150mm) |
| Borderless Printing Width |
10", 14", 17", 24" B2 (20.28"/515 mm), A1 (23.38"/594mm), A0 (33.11"841mm), 36" |
| Paper-Feed Method |
Roll Feed: One Roll, Top-loading, Front output
Cut Sheet:: One sheet, Top loading, Front output |
| Languages |
Language: GARO (Canon Proprietary), HP-GL/2, HP-RTL |
| Noise Level (Approx.) |
Operation: 50 dB (A) or less
Standby: 35 dB (A) or less
Acoustic Power: 6.6 Bels |
| Power Source |
AC-100-120V (50-60Hz) |
| Power Consumption |
Maximum: 140W or less
Standby 5W or less
Power Off: 1W or less (Compliant with Executive Order) |
| Operating Environment |
Temperature: 59°-86° F (15°-30° C)
Relative Humidity: 10-80% (No Condensation) |
| User-replaceable items |
Print Head (PF-04)
Maintenance Cartridge (MC-10)
Ink Tanks (PFI-102: C, Y, K, MBK), (PFI-104:M) |
| Software Included |
Canon Printer Driver
Digital Photo Front-Access
Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy
Advanced Preview)
HDI Driver for AutoCAD
PosterArtist Lite (PC Only)
Print Plug-in for Microsoft Word/Excel/PowerPoint (PC only) |
| Other Included |
Sample Pack Cut Sheet Coated Paper
Ethernet Card (built-in)
USB 2.0 High Speed Interface
User Manual CD
Quick Setup Guide (Poster)
Printer Reference Guide
Power Cord |
| Dimensions |
41.8" (H) x 51.3" (W) x 34.3" (D) |
| Weight |
Approximately 139 lbs. with stand |
