| Image Brightness |
7000 ANSI lumens |
| Image Contrast Ratio |
2500:1 |
| Image Size |
50 in - 600 in |
| Throw Ratio |
1.7 - 2.4:1 |
| Uniformity |
90 % |
| Resolution |
WUXGA (1920 x 1200) |
| Native Aspect Ratio |
Widescreen |
| Video Bandwidth |
162 MHz |
| Display Format |
2,304,000 pixels (1920 x 1200) |
| Max Sync Rate (V x H) |
85 Hz x 91 kHz |
| Lamp Type |
2 x UHM 300 Watt |
| Networking |
Ethernet |
| Data Link Protocol |
Ethernet, Fast Ethernet |
| Lens Type |
Standard lens |
| Focus Type |
Powered |
| Lens Aperture |
F/1.7-1.9 |
| Zoom Type |
Powered |
| Keystone Correction Direction |
Vertical |
| Vertical Keystone Correction |
-40 / +40 |
| Lens Shift Type |
Powered |
| Lens Shift Direction |
Horizontal, Vertical |
| Vertical Lens Shift |
50% |
| Horizontal Lens Shift |
10% / 10% |
| TV System |
NTSC, SECAM, PAL, PAL-N, PAL-M, NTSC 4.43, PAL 60 |
| Analog Video Signal |
RGB, S-Video, composite video, component video |
| Digital Video Standard |
Digital Visual Interface (DVI), High-Definition Multimedia Interface (HDMI) |
| Video Interfaces |
VGA, HDMI, composite video, S-Video, DVI |
| Video Modes |
1080/24p, 1080/60i, 480/60p, 720/60p, 1080/50i, 720/50p, 576/50p, 1080/50p, 1080/60p, 1080/30p, 480/60i, 1080/25p, 576/50i, 1035/60i, 1080/24sF |
| LAN/Wireless Image Transferring Protocol |
Wired LAN |
| Input Device Type |
External |
| Expansion / Connectivity |
Interfaces: 1 x DVI-D input - 24 pin digital DVI, 1 x component video / RGB input - BNC x 5, 1 x component video / RGB input - 15 pin HD D-Sub (HD-15), 1 x composite video input - BNC, 1 x S-video input - 4 pin DIN, 1 x remote control input - 9 pin D-Sub (DB-9), 1 x remote control input - mini-phone 3.5 mm, 1 x remote control output - mini-phone 3.5 mm |
| Power Device |
Internal |
| Nominal Voltage |
AC 120 V ( 50/60 Hz ) |
| Power Consumption Operational |
830 Watt
Standby: 0.2 Watt |
| Min Operating Temperature |
32 deg.F |
| Max Operating Temperature |
113 deg.F |
| Humidity Range Operating |
20 - 80% (non-condensing) |
| Dimensions (WxDxH) |
19.6x18.3x6.9" / 49.7x46.4x17.5cm |
| Weight |
35.9lbs / 16.2kg |
