Iogear 4-Port Dual View Dual-Link DVI KVMP Switch
Iogear 4-Port Dual View Dual-Link DVI KVMP Switch GCS1644
SKU: IGGCS1644 MFR: GCS1644
What's Included
What's Included With This Item:
- Iogear 1 x 4-Port Dual View Dual-Link DVI KVMP Switch
- 4 x Dual-Link DVI-D KVM Cable
- 4 x Dual-Link DVI-D Cable
- 1 x PS/2 to USB Adapter
- 1 x Firmware Upgrade Cable
- 1 x Power Adapter
- 1 x Installation Guide
- 1 x Warranty Card
- Iogear 3 Years Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Iogear 4-Port Dual View Dual-Link DVI KVMP Switch with Audio from IOGEAR allows you to control up to 4 computers using a single keyboard and mouse. Perfect for multimedia applications, the switch supports dual monitor configurations, an integrated 2-port USB 2.0 hub and audio switching. The switch features IOGEAR's Display Emulation Technology, which remembers your display's ideal resolution and refresh rate. This allows you to boot all of your computer simultaneously and switch between computers, while still maintaining ideal video settings for your particular monitor.
- Iogear 1 x 4-Port Dual View Dual-Link DVI KVMP Switch
- 4 x Dual-Link DVI-D KVM Cable
- 4 x Dual-Link DVI-D Cable
- 1 x PS/2 to USB Adapter
- 1 x Firmware Upgrade Cable
- 1 x Power Adapter
- 1 x Installation Guide
- 1 x Warranty Card
- Iogear 3 Years Warranty
- Dual View Dual-Link DVI support - Share 2 DVI monitors with a single keyboard and mouse,along4 computers
- High resolution - Up to 2560 x 1600
- 2-portUSB 2.0hub for peripheral sharing
- Asynchronous hotkey switching between KVM focus, USB peripheral and Audio ports
- IOGEAR's DynaSync reads and remembers the monitor's parameters (EDID) so there is no delay or change of video resolution when switching between, or booting computers
- Complete keyboard and mouse emulation for error free booting and real-time switching
- Computer switching via front panel push buttons or hotkeys
- Supports MAC and Sun keyboard and special keys
- Firmware upgradeable
- Plug & Play - no software installation required
- Buzzer ON/OFF via hotkey
- Multi OS platform support
| Max Computer Connections |
4 |
| Console Connectors |
Monitor: 2 x Dual Link DVI-I Female
Keyboard: 1 x USB Type A Female
Mouse: 1 x USB Type A Female
Audio: 1 x Mini Stereo Jack Female (Green)
Microphone: 1 x Mini Stereo Jack Female (Pink) |
| CPU Connectors |
Monitor: 8 x Dual Link DVI-I Female
Keyboard & Mouse: 4 x USB Type B Female
Audio: 4 x Mini Stereo Jack Female (Green)
Microphone: 4 x Mini Stereo Jack Female (Pink) |
| F/W Upgrade |
1 x 4-conductor 3.5mm Jack |
| Port Selection |
5 x Pushbutton |
| Power Connections |
1 x DC Jack |
| USB |
2 x USB Type A Female |
| LEDs |
Mode: 3 (Orange)
KVM: 4 (Green)
Audio: 4 (Green)
USB Peripherals: 4 (Green) |
| Emulation Keyboard |
USB |
| Emulation Mouse |
USB |
| Video Resolution |
Single Link DVI: 1920x1200; Dual Link DVI: 2650x1600 |
| Scan Interval |
1-99 seconds (5 seconds by default) |
| Voltage |
DC 5.3V |
| Amps |
2.4A |
| Operation Temperature |
0-50deg.C |
| Storage Temperature |
-20-60deg.C |
| Humidity |
0-80% RH, Non-condensing |
| Housing |
Metal |
| Dimensions (W x H x D) |
17 x 1.75 x 6.125" (43.2 x 4.4 x 15.6cm) |
| Weight |
5.8 lb (2.6kg) |
