| Channels |
Mixing: 32 mono, 4 stereo
Group: 8
Aux: 8
Main: Stereo |
| Functions |
Input: Gate, attenuator, 4-band PEQ, 2 compressors, delay, pan
Output: Attenuator, 4-band PEQ, compressor, delay |
| Number of Processors |
4 x SPC multi effects processors |
| AD/DA Conversion |
24-bit, 128x over sampling |
| Phantom Power |
+48VDC, On/off per 4 channels |
| Mic/Line Input |
Mic: 12
Line: 2 x stereo, 2 x 2-track |
| Line Output |
Stereo, monitor, 4 x Omni |
| Digital I/O |
ADAT (8 in, 8 out), 2-track in/out |
| Expansion |
Mini-YGDAI (16 in, 16 out) |
| Control |
USB to host, MIDI word clock I/O |
| Processing |
32-bit (58-bit accumulator) |
| Sampling Frequencies |
Internal: 44.1, 48, 88.2, 96 kHz
External: 44.1/88.2 kHz (-10%), 48/96 kHz (+6%) |
| Signal Delay |
< 1.6 ms (channel input to stereo out @ 48 kHz)
< 0.8 ms (channel input to stereo out @ 96 kHz) |
| Total Harmonic Distortion |
< 0.05% (channel input to stereo out, 20 Hz to 20 kHz @ +14 dBu into 600 ohms, 48 kHz)
< 0.01% (channel input to stereo out, 1kHz @ +24 dBu into 600 ohms, 48 kHz)
< 0.05% (20 Hz to 40 kHz @ +14 dBu into 600 ohms, 96 kHz)
< 0.01% (1kHz @ +24 dBu into 600 ohms, 96 kHz) |
| Frequency Response |
20 Hz - 20 kHz (+4 dBu into 600 ohms, 0.5-1.5 dB, 48 kHz)
20 Hz - 40 kHz (+4 dBu into 600 ohms, 0.5-1.5 dB, 96 kHz) |
| Dynamic Range |
110 dB (typical, DA converter, stereo out)
105 dB (typical, AD+DA, stereo out @ 48 kHz)
105 dB (typical, AD+DA, stereo out @ 96 kHz) |
| EIN |
-128 dBu |
| Residual Output Noise |
-86 dBu (stereo out off)
-86 dBu (90 dB S/N, stereo fader at nominal level and all channel input faders at minimum level)
-64 dBu (68 dB S/N, stereo fader at nominal level and 1 channel input fader at nominal level) |
| Crosstalk |
-80 dB, adjacent channels, input to output |
| Faders |
17 x 100 mm motorized faders |
| Connectors 1 |
17 x 100 mm motorized faders Connectors Inputs 1-12: 3-pin balanced XLR and 1/4" TRS phone
Inputs 13-16: Balanced 1/4" TRS phone
Inserts 1-12 In: Unbalanced 1/4" TRS phone
2-Track In: Unbalanced RCA (L/R)
Stereo Out: 3-pin balanced XLR
Omni Out: Balanced 1/4" TRS phone
Monitor Out: Balanced 1/4" TRS phone
Inserts 1-12 Out: Unbalanced 1/4" TRS phone
2-Track Out: Unbalanced RCA (L/R)
Phones: 1/4" Stereo phone, unbalanced
2-Track Digital In: RCA coaxial |
| Connectors 2 |
ADAT In: Optical
2-Track Digital Out: RCA coaxial
ADAT Out: Optical |
| Pad |
0, 20 (Ch. input 1-12) |
| Input Gain |
Ch 1-12: -60, -16 dB
Ch 13-16: -26, +4 dB |
| Input Impedance |
Ch 1-12: 3k ohms load, 50-600 ohms mic nominal, 600 ohms line nominal
Ch 13-16: 10k ohms load, 600 ohms line nominal
Insert 1-12 In: 10k ohms load, 600 ohms line nominal
2-Track In: 10k ohms load, 600 ohms line nominal |
| Input Sensitivity |
Ch 1-12: -70, -26, -6 dBu
Ch 13-16: -36, -6 dBu
Insert 1-12 In: -12 dBu
2-Track In: -10 dBV |
| Input Level |
Ch 1-12-: -60, -16, +4 dBu nominal, -40, +4, +24 dBu max
Ch 13-16: -26, +4 dBu nominal, -6, +24 dBu max
Insert 1-12 In: -2 dBu nominal, +18 dBu max
2-Track In: -10 dBV nominal, +10 dBV max |
| Output Impedance |
Stereo: 75 ohms source, 600 ohms line nominal
Omni: 150 ohms source, 10k ohms line nominal
Monitor: 150 ohms source, 10k ohms line nominal
Insert 1-12 Out: 600 ohms source, 10k ohms line nominal
2-Track: 600 ohms source, 10k ohms line nominal
Phones: 100 ohms source, 8-40 ohms line nominal |
| Output Level |
Stereo: +4 dBu nominal, +24 dBu max
Omni: +4 dBu nominal, +24 dBu max
Monitor: +4 dBu nominal, +24 dBu max
Insert 1-12 Out: -2 dBu nominal, +18 dBu max
2-Track: -10 dBV nominal, +10 dBV max
Phones: 4-12 mW nominal, 25-75 mW max |
| Digital Audio Format |
2 Track I/O: IEC-60958, 24-bit, 0.5 Vpp/75 ohms
ADAT I/O: ADAT, 24-bit |
| USB |
USB 2.0 type-B (24-bit, 0-3.3 V, audio and host) |
| MIDI |
5-pin DIN connectors for in, out and thru |
| Word Clock |
BNC in and out connectors (TTL/75 ohms) |
| Power Requirements |
100, 120, 220-240 VAC, 50/60 Hz |
| Power Consumption |
90 W |
| Dimensions (WxHxD) |
17.1x5.9x21.6" (436x148x548 mm) |
| Weight |
30.86 lbs (14 kg) |
