| Projector Display System |
Epson 3LCD, 3-chip optical engine
Poly-silicon TFT Active Matrix, 0.61-inch wide panel with MLA |
| Native Resolution |
1920 x 1080, 1080p
2,073,600 Pixels |
| Output |
HD, 2D, 3D, 1080p |
| Lumens Brightness |
White light output: up to 2,300 Lumens (ISO 21118 Standard)
Color light output: up to 2,300 Lumens |
| Aspect Ratio |
Native: 16:9 (Supports 4:3 - 16:10)
Media format: 16:9 |
| Lamp |
E-TORL 230W UHE
ECO mode: up to 5,000 hours
Normal mode: up to 4,000 hours |
| Throw Ratio |
1.32 - 2.15 |
| Screen Size Supported |
30 - 300" (0.76 - 7.6 m) |
| Keystone Correction |
Vertical: ±30 degrees (auto)
Horizontal: ±30 degrees (slide bar) |
| Contrast Ratio |
Up to 40,000:1 |
| Color Reproduction |
Full color: 1.7 billion colors |
| Color Processing |
Full 10-bit (digital only) |
| Lens |
18.2 - 29.2 mm, F=1.51 - 1.99
Projected widescreen image size: 100" (2.54 m)
Wide angle: 9.7' (3.0 m ), tele: 15.7' (4.8 m) |
| Zoom Ratio |
1.0 - 1.6 |
| Color Modes |
2D: Dynamic, Living room, Natural, Cinema, Auto
3D: 3D Dynamic, 3D Cinema |
| Input Signal |
Composite: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
Component: 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
HDMI: TMDS |
| Connectivity |
HDMI x2
RCA (composite) x1
RCA (component) x3
RCA (1 audio L/R) stereo x2
VGA D-sub 15 pin (computer input) x1
USB Type A x1
RS-232c (DB-9 pin) x1 |
| Input Video Compatibility |
2D: WUXGA 60Hz, WSXGA+ 60Hz, UXGA 60Hz, WXGA+, WXGA, SXGA+, SXGA, XGA, SVGA, VGA
3D: 720p 50/60Hz, 1080i 50/60Hz, 1080p, 50/60/24Hz |
| Computer Compatibility |
PC, Mac |
| Speaker |
Two integrated 10W stereo speakers |
| Operating Temperature |
41 - 95deg. F (5.0 - 35deg. C) |
| Power Supply Input Voltage |
100 - 240VAC +/-10%, 50/60 Hz |
| Power Consumption |
At 100 - 120VAC
ECO mode: 285W
Normal mode: 372W
Communication on: 0.26W standby
Communication off: 0.26W Standby |
| Fan Noise |
24 - 32dB |
| Security |
Kensington security lock port |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Remote Control |
Front and rear directional
Operating angle: +/- 30 degrees
Range: approximately 32' (10 m)
Batteries: AA x2 (included) |
| Parental Control |
Power Button Lock: Hinders projector from being turned on without parental supervision |
| Wireless Connectivity |
Compatible with Epson PowerLite Home Cinema 3020e and PowerLite Home Cinema 5020e 3D projectors
Power Supply: AC adapter, 100 - 240VAC, 50/60 Hz, 5V2A wall mount type
Power Consumption: 5V, 1.1 A
Operating Temperature: 41 - 95deg.F (5.0 - 35deg.C)
Interface: HDMI x5 input, HDMI output x1, optical audio x1 |
| Certifications |
U.S:
FCC Part 15B Class B (DoC)
UL60950-1 2nd edition
Canada:
ICES-003 Class B
CSA C22.2 No. 60950-1-07 |
| Dimensions |
16.6x14.4x5.5" (42.2x36.6x14 cm) |
| Weight |
13.3 lb. (6.0 kg) |
