| ADF Capacity |
750 Sheets |
| Scanning Technology |
CCD |
| Optical Resolution |
600 dpi |
| Output resolution |
100 / 150 / 200 / 240 / 300 / 400 / 600 dpi |
| Illumination |
White LEDs |
| Maximum Document Width |
304.8 mm (12") |
| Long Document Mode Length |
Up to 4.6m (180") |
| Throughput |
210 ppm |
| Minimum Document Size |
63.5x63.5 mm (2.5" x 2.5") |
| Paper Thickness and Weight |
With standard feeder: 45 g/m2 (12 lb.) bond to 200 g/m2 (110 lb.) index
With ultra-lightweight feeder accessory: 25 g/m2 (7 lb.) rice paper to 75 g/m2 (20 lb.) bond |
| Feeder/Elevator |
Automatic 750-sheet elevator design; automatic document feeder with four settings: continuous feed, 100-sheet, 250-sheet, 500-sheet and full 750-sheet batches |
| Multi-feed Detection |
5 independent ultrasonic zones |
| Connectivity |
USB 2.0 Hi-Speed Certified |
| Interface Support |
TWAIN, ISIS and WIA drivers, Kofax certified |
| Output Compression |
CCITT Group IV; JPEG or uncompressed output |
| Electrical Requirements |
100-240 V (international), 50/60 Hz |
| Power Consumption |
Sleep Mode < 4 watts; Running: < 250 watts; Standby: <1.0 watt |
| Environmental Factors |
2009 Energy Star qualified scanners, 2008 EuP |
| Acoustical Noise |
Standby mode: <44 dB(A); Scanning at 300 dpi <64 dB(A) |
| Recommended PC Configuration |
Microsoft Windows XP - P3 1 GHz, 1 GB RAM, USB 2.0
Microsoft VISTA - P4 1 GHz, 1 GB RAM, USB 2.0
Microsoft Windows 7 - P4 1 GHz, 2 GB RAM, USB 2.0 |
| Dimensions |
106.7x130.8x69.3 cm / 42x51.5x27.3" |
| Weight |
186 kg (410 lbs.) |
