| Sync voltage |
5 V (compatible with all cameras) |
| Energy (Ws/J) |
400 |
| Sync socket |
3.5 mm Jack |
| Power distribution |
Asymmetrical 2:1 ratio |
| Dimensions |
Ranger Quadra Hybrid including Battery box: 15x8.5x18.5cm / 5.90x3.34x7.28" |
| F-Stop (1m, 100 ISO, reflector 48deg.) |
At 100%: 64.5 |
| Weight |
2kg / 4.40lbs |
| Power range f-stop |
6.6 |
| Power range Ws |
100%: 25 - 400 - 66%
Output A: 17 - 268 - 33%
Output B: 8.2 - 132 |
| Power range |
1/1 - 1/32 |
| Power increments in f-stop |
1/10 to programmable 5/10 - 1/1 |
| Flash duration |
t0.5 at max. power in s: RQ S / A head
Output A (100%): 1/1200 / 1/2800
Output B (33%): 1/3000 / 1/5700
Output A+B (100%): 1/1500 / 1/4000 |
| Recycling, FAST in s |
Output A: 0.36 - 2.0
Output B: 0.17 - 0.73 |
| Recycling, SLOW in s |
Output A: 0.86 - 6.6
Output B: 0.33 - 2.3 |
| Color temperature in deg.K |
At max. power: 5500 |
| Auto Power Dumping |
Adjusts power settings automatically |
| Power stability |
± 0.5% |
| Modeling lamp mode |
On, off, programmable timer and continuous |
| Flashes out of one charged battery |
At min. power, SLOW / FAST recycle: 4800 / 4200
At max. power, SLOW / FAST recycle: 320 / 280 |
| Battery |
Lithium-Ion 16.8 V / 3.3 Ah |
| Quick charger: approx. recharge time |
1 h 30 min |
| EL-Skyport (Built-in) |
Integrated transceiver, 8 Frequency Channels and 4 Groups with full RX features |
| Sync voltage |
5 V (compatible with all cameras) |
| Sync socket |
3.5 mm Jack |
| Dimensions |
Ranger Quadra Hybrid including Battery box: 15x8.5x18.5cm / 5.90x3.34x7.28" |
| Weight |
2kg / 4.40lbs |
