Panasonic AK-HRP931 Remote Operation Panel
Panasonic AK-HRP931 Remote Operation Panel AK-HRP931
SKU: PCAKHRP931 MFR: AK-HRP931
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Panasonic AK-HRP931 Remote Operation Panel is a compact (136 x 55 x 419 mm) 1/3" rack unit that allows you to remotely adjust the parameters of the AK-HC931B camera system. Using the remote operation panel, you can manage the camera, CCU, tally and power supply (12 VDC) control signals as well as the RCP control (fader control) and power supply signals.
- Allows you to remotely adjust the parameters of the AK-HC931B camera system
- Compact (136 mm x 55 mm x 419 mm) 1/3" rack unit
- Allows you to manage the control signals of the camera, CCU, tally and power supply (12 VDC) as well as the RCP control (fader control) and power supply signals
- Also manages control signals for Preview
| Rack Mount |
1/3" rack size |
| Control |
CCU Control
Control signals (camera, CCU control)
Power supply (DC12 V)
Tally control signals
RCP Control
Control signals (fader control)
Power supply (DC12 V) |
| Power supply |
DC 12 V (supplied from CCU) |
| Power Consumption |
Approx. 6 W |
| Operating Temperature |
32 to 104 Deg. F (0 to 40 Deg. C) |
| Storage Temperature |
-4 to 140 Deg. F (-20 to 60 Deg. C) |
| Dimensions (W x H x D) |
5.4 x 2.2 x 16.5" (136 x 55 x 419mm) |
| Weight |
Approx. 5 lbs (2.3kg) |
