Cisco Catalyst 2960 48-Port 10/100 Ethernet Switch, 2 10/100/1000 Uplinks
Cisco Catalyst 2960 48-Port 10/100 Ethernet Switch WS-C2960-48TT-L
SKU: CI296048TTL MFR: WS-C2960-48TT-L
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Cisco Catalyst WS-C2960-48TT-L Intelligent Ethernet Switch is a fixed-configuration standalone device that provide desktop Fast Ethernet and Gigabit Ethernet connectivity, enabling enhanced LAN services for entry-level enterprise, mid-market and branch office networks. The Catalyst 2960 offers integrated security, including network admission control (NAC), advanced quality of service (QoS) and resiliency to deliver intelligent services for the network edge.
| Manageable |
Yes |
| Fast Ethernet Port |
Yes |
| Input Voltage Range |
100 V AC to 240 V AC |
| Number of Ports |
48 |
| Input Voltage |
110 V AC
220 V AC |
| Interfaces/Ports |
48 x RJ-45 10/100Base-TX LAN
2 x RJ-45 10/100/1000Base-T Uplink
1 x RJ-45 Console Management |
| Redundant Power Supply |
Yes |
| Management 1 |
Cisco Network Assistant
CiscoWorks Support
Device manager
Cisco Express Setup
CiscoView application
Cisco Network Assistant Software
Trivial File Transfer Protocol (TFTP) reduces the cost of administering software upgrades by downloading from a centralized location
Network Timing Protocol (NTP) provides an accurate and consistent timestamp to all intranet switches |
| Management 2 |
Cisco IOS CLI support provides a common user interface and command set with all Cisco routers and Cisco Catalyst desktop switches
Cisco Service Assurance Agent (SAA) support facilitates service-level management throughout the LAN
Switching Database Manager templates for security and QoS allow administrators to easily adjust memory allocation to the desired features based on deployment-specific requirements
VLAN trunks can be created from any port using standards-based 802.1q tagging |
| Management 3 |
Up to 255 VLANs per switch or stack and up to 128 spanning-tree instances per switch are supported.
Four thousand VLAN IDs are supported
Voice VLAN simplifies telephony installations by keeping voice traffic on a separate VLAN for easier administration and troubleshooting
Cisco VTP supports dynamic VLANs and dynamic trunk configuration across all switches |
| Management 4 |
SNMP v1, v2c and v3 and Telnet interface support delivers comprehensive in-band management and a CLI-based management console provides detailed out-of-band management
Cisco Discovery Protocol Versions 1 and 2 help enable a CiscoWorks network-management station for automatic switch discovery |
| Performance |
3.2Gbps Switching Fabric
6.8Gbps Forwarding Bandwidth
10.1Mpps Forwarding Rate For 64-byte Packet |
| Layer Supported |
2 |
| Connectivity Media |
Category 3 UTP 10Base-T
Category 4 UTP 10Base-T
Category 5 UTP 10/100Base-TX |
| Network Technology |
10/100Base-TX
10/100/1000Base-T |
| Dimensions (H x W x D) |
1.7" x 17.5" x 9.3" (4.3 x 44.4 x 23.6 cm) |
