| Printing Technology |
MicroPiezo ink jet technology |
| Maximum Print Resolution |
5760 x 1440 dpi |
| Print Speed |
Black: 37 ppm, Color: 37 ppm |
| ISO Print Speed |
Black: 19 ISO ppm, Color: 18 ISO ppm |
| Paper Sizes |
Letter (8.5" x 11"), A4 (8.3" x 11.7"), Legal (8.5" x 14"), 8" x 10", 4" x 6", 16:9 wide (4" x 7.11"), Envelope #10 (4.125" x 9.5"), A6 (4.1" x 5.8"), half letter (5.5" x 8.5"), user definable |
| Paper Weight |
Plain paper: 17 - 24 lb or 64 - 90 g/m2 (weight)
0.08 - 0.11 mm (thickness); Double-sided Matte Paper: up to 51 lb or 190 g/m2 (weight)
0.25 mm (thickness) |
| Paper Types |
Plain paper
Epson Bright White Paper
Epson Presentation Paper Matte
Epson Premium Presentation Paper Matte
Epson Premium Presentation Paper Matte Double-sided
White Address Label Ink Jet 14 labels / sheet (Avery)
Easy Peel White Mailing Labels 30 labels / sheet (Avery)
Label Paper 20 labels / sheet (Xerox) |
| Input Paper Tray Capacity |
Front paper cassette: Up to 500 letter-size sheets (plain paper); Rear automatic sheet feeder: Up to 150 letter-size sheets (plain paper)
Up to 60 legal-size sheets (plain paper, with optional support) |
| Output Paper Tray Capacity |
Plain paper: Letter size- up to 170 sheets
Legal size- up to 100 sheets
Envelopes- up to 15 |
| Ink Type |
DURABrite Ultra pigment ink |
| Interface |
Desktop: Hi-Speed USB 2.0
Network interface: 100Base-Tx / 10Base-Tx Ethernet |
| Network Printing Protocol |
TCP / IP, LPR, PORT9100 |
| Operating Systems |
Microsoft Windows 2000, XP / XP Professional x64 Edition, Windows Vista, Windows 7, Windows 7 x64 Edition, Windows Server 2003, Windows Server 2005 x64 Edition, Windows Server 2008, Windows Server 2008 x64 Edition
Mac OS 10.4.11, 10.5.x, 10.6.x |
| LCD Screen |
22 digit x 5-line LCD
3 LEDs
6 buttons |
| Controller Specifications |
Memory: 32MB
Printer control language emulations: Epson ESC / P-Raster, and ESC / P2
Resident Typefaces: compatible with all TrueType fonts and supported Windows and Macintosh fonts |
| Temperature |
Operating: 50 deg. to 95 deg. F (10 deg. to 35 deg. C)
Storage: 4 deg. to 104 deg. F (-20 deg. to 40 deg. C) |
| Humidity |
Operating: 20 - 80%
Storage: 5 - 85% (without condensation) |
| Sound Level |
Draft: 56 dB(A)
Default: 55 dB(A)
Best Photo: 38 dB(A) |
| Rated Voltage |
100 V - 120 V |
| Rated Frequency |
50 - 60 Hz |
| Rated Current |
1.1 A maximum |
| Power Consumption |
Printing mode: approximately 30 W
Ready mode: approximately 6.5 W
Sleep mode: approximately 3.5 W
Power off mode: approximately 0.2 W |
| Monthly Duty Cycle |
20,000 pages (recommended monthly volume of 4,000 pages) |
| Dimensions (W x D x H) |
18.9" x 21.6" x 12.3" / 480.06 x 548.64 x 312.43 mm |
| Weight |
24 lb / 10.89 Kg |
