| Output Power |
1600W @ 2 Ohms Stereo (per Channel)
1200W @ 4 Ohms Stereo (per Channel)
650W @ 8 Ohms Stereo (per Channel)
3200W @ 4 Ohms Bridged-Mono
2400W @ 8 Ohms Bridged-Mono |
| Sensitivity |
1.4 Vrms |
| Frequency Response |
(at 1 watt, 20 Hz - 20 kHz) +0 dB, -1 dB |
| Signal-to-Noise Ratio |
100 dB (A weighted) |
| Total Harmonic Distortion (THD) |
< 0.5% |
| Damping Factor 20 Hz to 1 kHz |
> 500 |
| Crosstalk (below rated power) |
20 kHz - 1 kHz: > 70 db |
| Input Impedance (nominal) |
20k ohms balanced, 10k ohms unbalanced |
| Maximum Input Signal |
+22 dBu typical |
| AC Line Voltage/Frequency Configurations |
100 VAC, 120 VAC, 220-240 VAC 50/60 Hz |
| AC Line Current |
10.5A; no more than 38W at idle |
| Operating Temperature |
0 Deg.C to 40 Deg.C at 95% relative humidity (non-condensing) |
| Level |
Two front-panel rotary level controls, one for each channel |
| Power Switch |
On/Off switch applies AC power to the amplifier |
| Sel/Prev/Next Buttons |
Three buttons near the LCD screen that are used to access menu items and front panel lockout |
| LCD Screen |
Backlit liquid crystal display that shows preset and processing status |
| Signal Indicator |
Green LED, one per channel, illuminates when a very low-level signal is present at input (may be used for troubleshooting cable runs). |
| -10 Indicator |
Green LED flashes when output signal exceeds -10 dB below clip. |
| -20 Indicator |
Green LED flashes when output signal level exceeds -20 dB below clip. |
| Ready Indicator |
Green LED, one per channel, illuminates when the amplifier is ready to produce audio. |
| Clip Indicator |
Red LED, one per channel, turns on at the threshold of audible distortion |
| Temp Indicator |
Red LED, one per channel, illuminates under excessive temperature conditions |
| Power Indicator |
Blue LED illuminates when the amplifier has been turned on and has power |
| Input Connectors |
XLR, one per channel |
| Link/Out Connector |
Loop-thru signal from input connector for linking another amplifier, one per channel. |
| Output Connectors |
Two Neutrik Speakon NL4MP output connectors. Channel-1 Speakon is wired with Ch. 1 and Ch. 2 outputs for use with optional single 4-conductor cable. Two binding post outputs (in parallel with Speakon connectors). |
| HiQnet USB Connector |
Type B, connects to HiQnet network. |
| Chassis |
Steel |
| Front Panel |
Cast-aluminum |
| Cooling |
Proportional speed fan with front-to-rear airflow. |
| Dimensions (W x H x D) |
19 x 3.5 x 12.25" (48.26 x 8.89 x 31.11cm) |
| Weight |
18.5 lbs (8.4kg) |
