| Wireless protocols |
Draft 802.11n
802.11a/b/g |
| Compatibility |
Interoperable with Wi-Fi Certified 802.11a, 802.11b and 802.11g and 802.11n draft 2.0 Mac computers, Windows-based PCs and other Wi-Fi devices
NAT, DHCP, PPPoE, VPN Passthrough (IPSec, PPTP and L2TP), DNS Proxy, SNMP, IPv6 (6to4 and manual tunnels) |
| Security |
Wi-Fi Protected Access (WPA/WPA2)
Wireless security (WEP) configurable for 40-bit and 128-bit encryption
MAC address filtering
NAT firewall
Support for RADIUS authentication
802.1X, PEAP, LEAP, TTLS, TLS, FAST
Time-based access control |
| Included software and accessories |
AirPort Utility for Mac and Windows
802.11n Enabler for Mac
Bonjour for Windows
Printed and electronic documentation |
| Interfaces |
802.11n wireless
One 10/100 Ethernet port for connecting a DSL, cable modem or Ethernet network
USB port for connecting a USB printer
3.5mm audio minijack for analog or optical digital sound
Built-in power supply |
| Electrical & environmental requirements |
100-240V AC, 50-60Hz; input current: 0.2 amps
Operating temperature: 32° to 95° F (0° to 35° C)
Storage temperature: -13° to 140° F ( -25° to 60° C)
Relative humidity (operating): 20% to 90%, noncondensing
Maximum operating altitude: 10,000 feet
Maximum storage altitude: 15,000 feet |
| Frequency bands |
2.4GHz or 5GHz |
| Radio output power |
20 dBm (nominal) |
| Agency approvals |
FCC Part 15 Class B, Canada RSS-210, EN 300-328, EN 301-489, EN 301 893, ARIB STD-T66, RCR STD-T33, AS/NZS 4268: 2003, UL 60950, CSA-C22.2 No. 60950 |
| Channels |
Channels 1-11, 36-48 and 149-165 |
| System Req for wireless client access |
For Mac Users: Mac with AirPort or AirPort Extreme wireless capability
For PC Users: PC with 802.11a/b/g or 802.11n draft 2.0 card |
| System Req for shared printing |
For Mac Users: USB printer, Mac with Mac OS X v10.2.7 or later
For PC Users: USB printer, PC with Windows XP (SP2) or Windows Vista; Bonjour for Windows (included on AirPort Express CD) |
| System Req Software |
For Mac Users with Mac OS X v10.4 or later can: Access an AirPort Express wireless network
Set up an AirPort Express Base Station
Use AirTunes to play music
Share a USB printer
Use Wi-Fi Protected Access (WPA/WPA2)
For PC Users:
* Windows XP or Windows Vista
WPA support requires a Wi-Fi Certified PC solution |
| Dimensions |
3.7 inches (94.01 mm) x 2.95 inches (75.00 mm) x 1.12 inches (28.5 mm) |
| Weight |
6.7 ounces (188 grams) |
| Warranty |
Apple warranty |
