| LCD: Display Area |
20.5" horizontal x 11.5" vertical; 23.6" diagonal |
| LCD: Optimum Resolution |
1920x1080 |
| LCD: Contrast Ratio |
1000:1 (typ); 20,000,000:1 (dynamic) |
| LCD: Viewing Angles |
170deg. horizontal, 160deg. vertical @ contrast ratio > 10:1 |
| LCD: Response Time |
5ms (typ) |
| LCD: Light Source |
Long life, 30,000 hrs. (typ) |
| LCD: Brightness |
300 cd/m2 (typ) |
| LCD: Panel Surface |
Anti-glare, hard-coating (3H) |
| Video Input: Analog |
RGB analog (75 ohms, 0.7/1.0 Vp-p) |
| Video Input: Digital |
DVI-D (TMDS, 100 ohms) |
| Video Input: Frequency |
Fh: 24-83kHz, Fv: 50-76Hz |
| Video Input: Sync |
Separate Sync/Composite Sync/SOG |
| Compatibility |
PC: VGA up to 1920x1080 non-interlaced Mac: Power Mac up to 1920x1080 |
| Connector: Analog |
15-pin mini D-sub (VGA) |
| Connector: Digital |
DVI-D |
| Connector: Audio |
3.5 mm audio in / 3.5 mm audio out |
| Connector: Power |
3-pin plug (CEE22) |
| Audio Speakers |
2x2.5-watt |
| Power: Voltage |
AC 100-240V (universal), 50/60Hz |
| Power: Consumption |
23W (typ) |
| Ergonomics |
Tilt: Down 5deg., Up 20deg. |
| Controls: Basic |
Power, up, down |
| Controls: OSD |
Auto Image Adjust, Contrast/Brightness, Input Select (D-SUB, DVI), Audio Adjust (Volume, mute), Color Adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User Color [R, G, B]), Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine Tune, Sharpness, Dynamic Contrast, Aspect Ratio, Display Mode, ECO Mode ), Setup Menu (Language, Resolution Notice, OSD Position, OSD Timeout, OSD Background, Auto Power Off, Sleep), Memory Recall |
| Operating Conditions: Temperature |
32-104deg. F (0-40deg. C) |
| Operating Conditions: Humidity |
20-90% (non-condensing) |
| Regulations |
BSMI, CCC, PSB, C-Tick, KC, e-standby, CE, Ergo, Gost-R/Hygienic, Ukraine, SASO, UL/cUL, FCC-B, ICES-B,TUV-S/UL-AR S Mark, NOM, WEEE, RoHS |
| Wall Mount |
VESA 100mm x 100mm |
| Power Management |
ENERGY STAR standards |
| Dimensions (W x H x D) |
With Stand: 22.3" x 17.4" x 8.4" (566.4mm x 441.96mm x 213.4mm) Without Stand: 22.3" x 14.5" x 2.0" (566.4mm x 368.3mm x 50.8mm) |
| Weight |
With Stand: 9.9 lbs(4.49 kg) Without Stand: 8.9 lbs(4.0 kg) |
