Kramer Electronics FC-7501 Format Converter
Kramer Electronics FC-7501 Analog Video FC-7501
SKU: VDKRFC7501 MFR: FC-7501
Please note! This is a Special Order Item and is Non Cancelable and Non Returnable.
We Charge you when you place your order. Approximate arrival at Adorama 1 - 2 Weeks from date of order.
What's Included
What's Included With This Item:
- Kramer Electronics FC-7501 Format Converter
- Power Supply
- Windows-Based Kramer Electronics Control Software
- Kramer Electronics Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The FC-7501 is a format converter for composite video, s-Video or component video (YUV) signals. It converts either PAL, SECAM and NTSC composite video, s-Video, or component (YUV) signals into 2 SDI (SMPTE 259) signals simultaneously.
- Kramer Electronics FC-7501 Format Converter
- Power Supply
- Windows-Based Kramer Electronics Control Software
- Kramer Electronics Warranty
- Multi-Standard This device will accept NTSC or PAL signals
- Composite or Y/C: Although this unit is designed to process component signals, it will also convert composite or Y/C, utilizing the same BNC connectors
- Excellent Quantization: Featuring 10-Bit Accuracy
- Processing Amplifier: Able to video parameters via RS-232 and a PC
- Dual SDI Outputs: Two SDI outputs are featured, offering the user a simple SDI DA
| Input |
1 composite video: 1Vpp/75ohm (Y) looping on BNC connectors with a termination switch; 1 (B-Y): 0.7Vpp/75ohm looping on BNC connectors with a termination switch; 1 (R-Y)/C 0.7Vpp/0.3Vpp/75ohm looping on BNC connectors with a termination switch |
| Outputs |
2 SDI on BNC connectors |
| Video Standards |
CV, YC: NTSC (M, Japan, 4.43), PAL (B, D, G, H, I, M, N, Nc) and SECAM (B, D, G, K, K1, L) |
| Bandwidth (-3db) |
6MHz |
| Resolution |
10 bits |
| Luminance Non-linerarity |
1% (worst case) |
| K-factor |
0.10% |
| S/n Ratio |
57dB (worst case) |
| Chroma/luma Delay |
<10ns |
| Sdi Pixel Jitter |
<500ps (10Hz HPF) with PLL option board. <1ns (10kHz HPF) without PLL option board |
| Input Coupling |
DC or AC via internal jumpers |
| Power Source |
12V DC, 320mA |
| Dimensions (W x D x H) |
8.7 x 7 x 1.7"/22 x 18 x 4.5cm |
| Weight |
2.9 lbs/1.3 kg |
