Cambo MPT-9 Mechanical Pan and Tilt for the Standard V-15 Boom Set #99134800
Cambo MPT-9 Mechanical Pan and Tilt 99134800
SKU: CAM99134800 MFR: 99134800
Please Note! This Special Order Item is Non Cancelable and Non Returnable. We Charge you when you place your order. Approximate arrival at Adorama 7-14 business days.
What's Included
What's Included With This Item:
- Cambo MPT-9 Mechanical Pan and Tilt
- Control Frame for V-15
- Cable Set
- Camera Unit
- Control Unit
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Cambo MPT-9 for Standard V-15 Boom Set is the control pan and tilt for the standard V-15 boom set. This kit allows the operator to mechanically control the camera pan and tilt while operating the boom or crane. The MPT-9 has a fluid friction system in the Head Unit, which enables you to make very smooth pan and tilt movements. The MPT Control Unit is also mountable as a separate pan and separate tilt control with two independent handles. Depending on what you are shooting the mpt-9 is controllable in more than one way. Combined Videoboom and MPT movements are possible when the control unit is mounted as a combined pan-tilt control. The free hand can control the Videoboom movement.
- Cambo MPT-9 Mechanical Pan and Tilt
- Control Frame for V-15
- Cable Set
- Camera Unit
- Control Unit
- The standard control offers one handle controlling both pan and tilt features
- This device is mounted on a modular tube frame that allows specific setup of the V-15 boom/crane
- The MPT-9 is a combined fluid/friction system offering smooth pan and tilt. Friction level is adjustable by user for more control in specific applications
| Max. Camera Load |
10kg |
| Pan Range |
340° |
| Tilt Range |
340° |
| Mpt-9 Head (Packed Size) Dimension |
447x130x310mm (h x w x d) |
| Control Unit Dimension (h x w x d) |
229x131x139mm (Combined Control) |
| Control Frame V15 (Mounted) Dimension |
116x558x305mm (h x w x d) |
| Mpt-9 Head Weight |
2.3kg |
| Control Unit + Cable Set Weight |
2.7kg |
| Control Frame V15 Weight |
0.8kg |
