| Projector Display System |
0.63" 3LCD Polysilicon Active-Matrix TFT x 3 |
| Native Resolution |
XGA (1024 x 768) |
| Number of Pixels |
786,432 x 3 = 2,359,296 |
| Lumens Brightness |
White Light Output (Brightness): 2700 ANSI Lumens (Normal Mode) 1800 ANSI Lumens (Eco Mode) Color Light Output: 2700 ANSI Lumens |
| Contrast Ratio |
3000:1 |
| Colors |
8-Bit/Color, 16.7M Colors |
| Aspect Ratio |
4:3, 16:9 Compatible |
| Computer Compatibility |
IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA (Compressed), MAC 16" |
| System |
NTSC/PAL/SECAM/PAL-M/PAL-N/NTSC4.43/PAL60 |
| Component |
Component Video SDTV: 480i, 480p, 576i, 576p HDTV: 720p (@50/60Hz), 1080 (@50/60Hz), 1080p (@50/60Hz) |
| HDTV Compatibility |
HDMI Video Signal: 525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60) Plug & Play: DDC2B |
| Focus/Zoom Adjusting |
Manual/Manual 1.2x |
| Lens Shift |
No |
| Recommended Projection Size |
30-300" (76-762 cm) Distance to Width: 1.5 (Wide), 1.8 (Tele) |
| Keystone Correction |
Auto V Keystone ±30deg. (@XGA 60Hz) 9:1 Upward Shift, Fixed |
| Ceiling Mountable |
Yes |
| Rear Screen Projection |
Yes |
| Projection Tilt Option |
Yes |
| Built-in Speaker |
16W Mono (8W x 2) |
| Inputs/Outputs 1 |
Digital Input: 1 x HDMI (HDCP Compatible) Computer Input: 2 x 15-pin Mini D-sub Monitor Output: 1 x 15-pin Mini D-sub (RCA Combination) Video Input: 1 x RCA for Component 2 x Component D-sub (Shared with Analog RGB) 1 x RCA for Composite 1 x Mini-DIN for S-Video |
| Inputs/Outputs 2 |
Audio Input: 2 x Stereo Mini Jack 1 x Pair RCA (L/R) 1 x Microphone Jack (Stereo Mini) Audio Output: 1 x Pair RCA (L/R) USB Type A: 1 x USB Type A (for PC-Less Presentation or Wireless Adapter) USB Type B: 1 x USB Type B (for USB Display or USB Mouse Control) Wired Network: 1 x RJ-45 Wireless Network Option, IEEE 801.11b/g/n Ready Control: 1 x 9-pin D-sub for RS-232C Control |
| Lamp (Bulb) |
210W UHP Lamp Life: 3000 Hours (Normal Mode)/6000 Hours (Eco Mode) |
| Fan Noise |
29dB (Eco Mode)/36dB (Normal Mode) |
| Remote Control |
IR Wireless |
| OSD Languages |
English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkish, Arabian, Persian, Czechoslovakian, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil) |
| Power Requirements |
100-120V/220-240V Auto Switching |
| Power Consumption |
310W/<1W (AC 220-240V) |
| Certifications |
UL/C-UL, FCC Part 15 Class B, CE, AS/NZS CISPR22 Class B |
| Dimensions (W x H x D) |
Excluding Feet and Extrusions: 12.5 x 3.9 x 11.3" (317 x 98 x 288mm) |
| Weight |
7.8 lb (3.5kg) |
