CyberPowerPC CP800AVR AVR 800VA / 450W UPS
CyberPowerPC CP800AVR AVR Series Computer Battery Backup CP800AVR
SKU: CYBCP800AVR MFR: CP800AVR
What's Included
What's Included With This Item:
- CyberPowerPC CP800AVR AVR 800VA / 450W UPS
- PowerPanel Personal Edition Software
- RS-232 Serial Cable
- Coaxial Cable
- RJ11 Cable
- USB Cable
- User Manual
- CyberPowerPC 3 Years Limited Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The CyberPowerPC AVR Series CP800AVR uninterruptible power supply (UPS) safeguards small office workstations, networks and home entertainment systems against surges, spikes, sags and brownouts, protecting equipment and valuable data during a power outage. Its automatic voltage regulation (AVR) monitors incoming AC power and maintains a safe voltage level.
The CP800AVR unit has a capacity of 800VA/450Watts, eight NEMA 5-15R receptacles, widely-spaced to accommodate transformer-based plugs. Its compact design allows for horizontal or vertical placement, or it can be conveniently mounted on a wall. This UPS has a maintenance-free, user-replaceable 12V/8.5Ah battery and offers connectivity via one HID USB and one DB9 serial port. Protection for phone/network (RJ11/RJ45) and cable/coax (RG-6) is included. EMI/RFI filters increase the immunity of the load to noise disturbances. PowerPanel Personal Edition Smart Management software is included to monitor the vitals of the UPS and safely shut down the system in case of a power outage.
- CyberPowerPC CP800AVR AVR 800VA / 450W UPS
- PowerPanel Personal Edition Software
- RS-232 Serial Cable
- Coaxial Cable
- RJ11 Cable
- USB Cable
- User Manual
- CyberPowerPC 3 Years Limited Warranty
- Automatic Voltage Regulation: AVR boosts the AC power and maintains a safe voltage level without switching to battery-mode, conserving battery life and delivering a cleaner signal to connected equipment
- Ultra-Quiet Operation: Lowest sound emissions of any UPS in its class
- EMI/RFI Filters: Shielding against electromagnetic interference and radio frequency signals prevents line noise ("humming") over telephone lines or audio systems
- Transformer-Spaced Outlets: Widely-spaced outlets accommodate large transformer-based plugs without compromising the utility of other outlets
- USB Connectivity: HID compliant USB port enables full integration with built-in power management and auto shutdown features of Windows, Linux and Mac OS X
- Convenient Mounting: Multiple mounting options: horizontal, vertical, cabinet and wall
- LED Indicators: LED status lights indicate Power-On and wiring faults
- Audible Alarms: Distinctive tones identify when the unit is running on battery power, if it is overloaded or when the battery is low
- Resettable Circuit Breaker: The user may use this convenient unit reset switch in case of an overload
- PowerPanel Personal Edition: In event of a power outage, PowerPanel PE saves open files and "hibernates" the PC to increase the run-time on the UPS unit. PowerPanel is easily installed on any Windows-based PC and uses minimal system resources
- Windows Compatibility: The PowerPanel power management software has been fully tested and is compatible with Windows 2000, 2003, XP 32/64, Vista 32/64, 7 and Server 2008
| UPS Topology |
Line-Interactive (AVR) |
| Energy Saving |
Yes - GreenPower UPS Bypass Technology |
| Voltage |
100Vac - 140Vac |
| Frequency |
60Hz +/- 3Hz |
| Plug Type |
NEMA 5-15P |
| Plug Style |
Right angle |
| Cord Length |
6' / 1.82 m |
| Output |
VA: 800 Watts: 450 |
| Automatic Voltage Regulation |
Yes |
| On Battery Voltage |
120Vac +/- 5% |
| On Battery Frequency |
60Hz |
| On Battery Waveform |
Simulated sine wave |
| Overload Protection |
Internal circuitry limiting / circuit breaker |
| Outlets: Total |
8 |
| Outlets: Battery & Surge Protected |
4 |
| Outlets: Surge-Only Protected |
4 |
| Outlets: Widely Spaced |
4 |
| Transfer Time |
4ms |
| Runtime at Half Load (min) |
10 |
| Runtime at Full Load (min) |
3 |
| Battery Type |
Sealed lead acid |
| Battery Size |
12V/9AH |
| User Replaceable |
Yes |
| Typical Recharge Time |
8 Hours |
| Replacement Battery |
BB Battery - HR9-12 |
| Battery Quantity |
1 |
| Surge Suppression |
890 Joules |
| Maximum Surge Current |
36,000 Amps |
| Phone / Ethernet RJ11 / RJ45 |
1-In, 1-Out (Combo) |
| Coax Protection RG6 |
1-In, 1-Out |
| HID Compliant USB Port |
Yes |
| Serial Port |
Yes |
| Management Cable |
USB Cable |
| LED Indicators |
Power on, wiring fault |
| Audible Alarms |
Input fault, battery fault, low battery, overload |
| Software |
PowerPanel Personal Edition |
| Form Factor |
Compact |
| Keyhole Mounting Slots |
Yes |
| Operating Temperature |
32 Deg.F to 95 Deg.F / 0 Deg.C to 35 Deg.C |
| Operating Humidity |
0% - 95% non-condensing |
| Certifications |
UL1449, cUL, FCC DOC Class B |
| ROHS |
ROHS Compliant |
| Dimensions (W x H x D) |
11" x 6.5" x 3.5" / 27.9 x 16.5 x 8.8 cm |
