| Intrusion Detection and Prevention |
In-line Mode (Routing/Bridge) Zone-Based IDP Inspection Customizable Protection Profile Signature-based Deep Packet Inspection Automatic Signature Updates Custom Signatures Traffic Anomaly Detection and Protection Flooding Detection and Protection Protocol Anomaly Detection and Protection: HTTP/ICMP/TCP/UDP |
| Anti-Virus |
ICSA-Certified ZyXEL Anti-Virus or Kaspersky Anti-Virus Stream-Based Anti-Virus Covers Top Active Viruses in the Wild List Scans HTTP/FTP/SMTP/POP3/IMAP4 Automatic Signature Updates No File Size Limitation Blacklist/Whitelist Support |
| Content Filtering |
URL Blocking, Keyword Blocking Exempt List (Blacklist and Whitelist) Blocks Java Applet, Cookies and Active X Dynamic URL Filtering Database (Powered by BlueCoat) |
| User Licenses |
Unlimited |
| Networking |
Routing Mode/Bridge Mode/Mixed Mode Layer 2 Port Grouping Ethernet/PPPoE/PPTP Tagged VLAN (802.1Q) Virtual Interface (Alias Interface) Policy-Based Routing (User-Aware) Policy-Based NAT (SNAT/DNAT) RIP v1/v2 OSPF IP Multicasting (IGMP v1/v2) DHCP Client/Server/Relay Built-in DNS Server Dynamic DNS |
| Authentication |
Internal User Database Microsoft Windows Active Directory External LDAP/RADIUS User Database ZyWALL OTP (One Time Password) Forced User Authentication (Transparent Authentication) |
| System Management 1 |
Role-Based Administration Multiple Administrator Login Multi-Lingual Web GUI (HTTPS/HTTP) Object-Based Configuration Command Line Interface (Console/Web Console/SSH/TELNET) Comprehensive Local Logging Syslog (send to up to 4 servers) E-mail Alert (send to up to 2 servers) SNMP v2c (MIB-II) |
| System Management 2 |
Real-Time Traffic Monitoring System Configuration Rollback Text-Based Configuration File Firmware upgrade via FTP/FTP-TLS/Web GUI Advanced Reporting (Vantage Report) Centralized Network Management (Vantage CNM) |
| 3G Support |
Advanced Wireless Security Transmission with WEP Encryption and WPA/WPA2 Support PCMCIA: Sierra Wireless AC850 USB: Huawei E220 |
| Certifications |
ICSA Certified Firewall ICSA Certified IPSec VPN ICSA Certified Anti-Virus |
| Standards Compliance |
HSF (Hazardous Substance Free): RoHS and WEEE EMC: FCC Part 15 Class B, CE-EMC Class B, C-Tick Class B, VCCI Class B Safety: CSA International (ANS/UL60950-1,CSA60950-1, EN60950-1, IEC60950-1) |
| Memory size |
256 MB DDR2 RAM/256 MB Flash |
| Interface |
GbE x 7 (RJ-45 with) Auto-negotiation and Auto MDI/MDI-X |
| Console |
RS-232 (DB9F) |
| AUX |
RS-232 (DB9M) |
| LED Indicator |
PWR, SYS, AUX, CARD |
| Reset Button |
Yes |
| Expansion Card Slot |
Yes |
| USB Ports |
2 |
| Power Requirements |
Input: 100 - 240 V; 1.2 A, 50 - 60 Hz Output: 12 V; 3.5 A |
| Operating temperature |
0deg.C - 50deg.C/32deg.F - 122deg.F |
| Storage temperature |
-30deg.C - 60deg.C/-22deg.F - 140deg.F |
| Operating humidity |
5% - 90% (noncondensing) |
| Dimensions (W x D x H) |
242 x 175 x 35.5 mm/9.5 x 6.9 x 1.4 in |
| Weight |
1.2 Kg/2.6 lb |
