AJA Hi5 3D 3G/HD-SDI to HDMI 1.4a Mini Converter with Power Supply
AJA Video
AJA Hi5 3D Mini Converter HI5-3D
SKU: AJHI53D MFR: HI5-3D
What's Included
What's Included With This Item:
- AJA Hi5 3D Mini Converter
- HDMI Cable
- Universal Power Supply (DWP-U-R1)
- AJA 5 Years Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Hi5-3D is a 3D video multiplexer that combines two 3G or HD-SDI Inputs into various multiplexed 3D formats for output on HDMI 1.4a and HD-SDI. The HDMI 1.4a output supports EDID transactions that allow automatic 2D/3D configuration per the HDMI monitor's capabilities. Input SDI 2 will be frame synchronized to input SDI 1 in 3D Modes. Embedded SDI input audio is embedded in both the HDMI and SDI outputs. 2 channel RCA audio output is also supported with user control of channel selection. The Hi5-3D supports AJA's Mini-Config application for user configuration and firmware download.
- AJA Hi5 3D Mini Converter
- HDMI Cable
- Universal Power Supply (DWP-U-R1)
- AJA 5 Years Warranty
- The Hi5-3D supports, depending on the video format, "side-by-side", "top-bottom" and "frame- packing" 3D modes. The "side-by-side" and "top-bottom" modes involve compressing, either horizontally or vertically, each input for combining into a single video stream at the same rate of the inputs
- The Hi5-3D works with both 2D and 3D inputs. When in the 2D mode, the input is simply passed to the output unmodified. In the 3D mode, the Hi5-3D supports the minimum required 3D modes as defined by the CEA for HDMI 1.4a televisions
- The Hi5-3D supports both dipswitch control and host control via the Mini-Config application. One of the dipswitches is a "Local/Remote" switch
- When in the "Local" mode, the remaining dipswitches support a subset of the user controls. When in the "Remote" mode, AJA's Mini-Config application controls the unit (or control as last set)
| Input Formats |
720p 50/59.94/60
1080i 50/59.94/60
1080p23.98
1080p24
1080p25 |
| Video Inputs |
Dual 3G and HD-SDI (auto-selected), SMPTE-292/296/424, 2 x BNC, 1 SDI for left eye input (10-bit), 1 SDI for right eye input (10-bit) |
| Video output |
10-bit HDMI v1.4a, 1 3G/HD-SDI output, 10-bit |
| Audio Outputs |
HDMI embedded audio, 2 or 8 channels
2 RCA-style analog outputs at -10dBV (nominal), User assignable channels |
| Power |
+5-20 VDC regulated, 5 watts (AJA power supply model DWP or DWP-U recommended) |
| Dimensions |
5.8 x 3.1 x 1.0in / 147 x 79 x 25mm |
