Kramer Electronics OC-2 Dual Channel Video Isolator
Kramer Electronics OC-2 Dual Channel Video Optical Line Isolator OC-2
SKU: VDKROC2 MFR: OC-2
Please note! This is a Special Order Item and is Non Cancelable and Non Returnable.
We Charge you when you place your order. Approximate arrival at Adorama 1 - 2 Weeks from date of order.
What's Included
What's Included With This Item:
- Kramer Electronics OC-2 Dual Channel Video Isolator
- Power Cord
- Kramer Electronics Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Kramer Electronics OC-2 reduces or eliminates hum and herringbone interference resulting from a ground loop. This model offers two channels of video isolation. The inputs and outputs are BNC connections isolated from the power supply ground.
- Kramer Electronics OC-2 Dual Channel Video Isolator
- Power Cord
- Kramer Electronics Warranty
- Powered: This unit offers optical isolation, therefore offering a linear response and wide frequency range capability
- Level Control: Input level, Output level and EQ controls offer the user optimum control of the video signal
- Dual Channel: This device offers two separate channels of video line isolation with adjustment for each channel
| Input |
2 composite video, 1Vpp/75ohm on BNC connectors |
| Output |
2 composite video, 1Vpp/75ohm on BNC connectors |
| Bandwidth (-3db) |
20MHz |
| S/n Ratio |
69dB |
| Power Source |
230V AC, 50/60Hz, (115V AC, USA) 2.3VA |
| Dimensions (W x D x H) |
8.7 x 7 x 1.7"/22 x 18 x 4.5cm |
| Weight |
2.9 lbs/1.3 kg |
