| Focal Length (35mm equivalent) |
Movie Mode: 26.8mm - 321.6mm (16:9), 32.8mm-393.6mm (4:3); Photo Mode: 26.8mm - 321.6mm (16:9), 32.8mm-393.6mm (4:3) |
| Aperture |
F1.8-3.4 |
| Digital Zoom |
160x |
| Extended Zoom |
20x |
| Filter Diameter |
30mm |
| Focal Distance |
f = 2.9mm - 34.8mm; f =1/8inch - 1 3/8inch |
| Lens Stabilization |
Optical SteadyShot image stabilization w/ Active mode (Wide to Tele) |
| Lens Type |
G Lens |
| Minimum Focus Distance |
Approx. 1cm (Wide), Approx. 50cm (Tele), Approx. 25cm (Tele Macro) |
| Optical Zoom |
12x |
| Steady Shot Active Mode |
29.1-582.7mm |
| Auto Iris Control |
F1.8 - F10 |
| Backlight Compensation |
Yes (Auto) |
| D-Range Optimizer |
Yes |
| Exposure Settings |
Auto; Flexible Spot (Touch Panel) |
| Gain Control |
Auto |
| LOW LUX Mode |
Yes |
| Metering Modes |
Multi-segment / Spot |
| Minimum Illumination |
Standard: 6 lux (1/60 Shutter Speed); Low Lux: 3 lux (1/30 Shutter Speed) |
| Noise Reduction |
Yes |
| Scene Mode(s) |
Auto / Twilight / Twilight Portrait (Photo Mode only) / Sunrise & Sunset / Fireworks / Landscape / Portrait / Spotlight / Beach / Snow |
| White Balance Mode |
Auto / Onepush / Outdoor / Indoor |
| Projector Endurance (Battery Life) |
Approx. 85mim(Supplied Battery) |
| Projector Resolution Output |
640x360 |
| Projector Throw Distance |
16ft (5m) (for 100"diagonal) |
| SD Output |
Composite Video Out (A/V connecting cable (supplied)); Component Video Out (Component A/V cable (supplied)); S Video Out (A/V connecting cable with S Video) |
| Remote Jack |
Integrated into A/V Remote terminal |
| Remote Commander |
Yes |
| A/V Remote Terminal |
Video / Audio / Remote |
| Accessory Shoe |
Yes (Active Interface Shoe) |
| BRAVIA Sync |
Yes |
| DC IN |
Yes |
| Direct Copy |
Yes |
| HD Output |
HDMI Out (mini) (supplied) |
| HDMI Terminal |
Yes (mini) |
| Headphone Jack |
Stereo Minijack |
| Memory Card Slot |
Memory Stick PRO Duo and SD/ SDHC/ SDXC media compatible |
| Microphone Input |
Stereo Minijack |
| PhotoTV HD |
Yes |
| USB Port(s) |
TypeA, mini-AB/USB2.0 Hi-speed (mass-storage/MTP) |
| Color Filter System |
ClearVid array |
| Effective Picture Resolution |
Approx. 5020K pixels (16:9) |
| Imaging Sensor |
1/3.91" (4.6mm) Back-illuminated Exmor R CMOS Sensor |
| Pixel Gross |
Approx. 5430K pixels |
| Processor |
BIONZ Image processor |
| Angle Adjustment |
Opening Angle: max. 90 deg., Turning Angle: max. 270 deg. |
| Brightness Control |
Yes (Menu) |
| Coverage |
1 |
| Grid Display |
Guide Frame |
| LCD Type |
3.0" Xtra Fine LCD display (921K) w/ TruBlack technology |
| Touch Panel |
Yes |
| Shutter Speeds |
Self-timer: Approx. 10sec. (Still Image/ Golf Shot); Shutter Speed (Standard): 1/60 - 1/10000; Shutter Speed Auto Control Range: 1/8 - 1/10000; Shutter Speed (Smooth Slow Rec): 1/250 - 1/10000 (Standard); Scene Selection: 1/8 - 1/10000; LOW LUX: 1/30 - 1/10000 |
| Drive Mode |
Photo Mode: Single-shot / Self-timer |
| Self-timer |
10sec.(Still Image/Golf Shot) |
| Still Image Size 4:3 |
Movie mode: 15.3 megapixels 4:3 (4512x3384); Photo mode: 15.3 megapixels 4:3 (4512x3384) |
| Video Mode |
HD PS: Approx. 28Mbps / FX: Approx. 24Mbps / FH: Approx. 17Mbps / HQ: Approx. 9Mbps / LP: Approx. 5Mbps; STD HQ: 9Mbps |
| Audio Format |
Dolby Digital 5.1ch, Dolby Digital 5.1Creator; Dolby Digital 2ch Stereo, Dolby Digital Stereo Creator |
| Dual Record |
20.4 megapixels 16:9 (6016x3384); 10.0 megapixels 16:9 (4224x2376); 2.1 megapixels 16:9 (1920x1080) |
| Internal Media |
Flash Memory 32GB |
| Media Type |
Internal Flash Memory; Memory Stick PRO Duo (Mark 2); Memory Stick PRO-HG Duo; SD/ SDHC/ SDXC Memory Card (Class 4 or Higher) |
| Mic Level Control |
Yes (2steps) |
| Microphone/Speaker |
Built-in Zoom Microphone; Clear Phase Stereo Speaker |
| Photo Capture from Movie |
2.1 megapixels 16:9 (1920x1080); 0.3 megapixels 4:3 (640x480); 0.2 megapixels pixels 16:9 (640x360) |
| Recording and Playback Times (2ch) |
HD PS: Approx. 2h20m (Approx. 2h20m); HD FX: Approx. 2h45m (Approx. 2h45m); HD FH: Approx. 3h50m (Approx. 2h45m); HD HQ: Approx. 6h50m (Approx. 6h10m); HD LP: Approx. 11h55m (Approx. 7h5m); STD HQ: Approx. 7h5m (Approx. 6h35m) |
| Recording and Playback Times (5.1ch) |
HD PS: Approx. 2h20m; HD FX: Approx. 2h45m; HD FH: Approx. 3h45m; HD HQ: Approx. 6h40m; HD LP: Approx. 11h35m; STD HQ: Approx. 6h55m |
| Still Image File Format |
DCF Ver. 2.0 compatible, Exif Ver. 2.3 compatible, MPF Baseline compatible |
| Still Image Max Effective Resolution |
20.4 megapixels |
| Still Image Mode |
JPEG |
| Still Image Size 16:9 |
Movie mode: 20.4 megapixels 16:9 (6016x3384); Photo mode: 20.4 megapixels 16:9 (6016x3384) |
| Video Actual (Pixel) |
Approx.5,020K pixels(16:9), Approx.3,760K pixels(4:3) |
| Video Format |
HD: MPEG4-AVC/H.264 AVCHD 2.0 format compatible (1080/60p:original format); STD: MPEG2-PS |
| Video Resolution |
HD: 1920x1080/60p (PS), 24p, 60i (FX, FH), 1440x1080/60i (HQ, LP); STD: 720x480/60i |
| Video Signal |
NTSC color, EIA standards |
| Wind Noise Reduction |
Yes (Off /On) |
| AF Illuminator |
Yes |
| AF Modes |
Auto / Manual (Touch Panel / Dial) |
| Focus Area |
Full range Focus / Spot Focus |
| Focus |
Tracking Focus |
| Focus System |
Contrast AF |
| Manual Focus Assist |
Magnified display for precise manual focus; Peaking Display |
| Flash Compensation |
Yes (3 steps) |
| Flash Coverage |
Approx. 0.3m - 2.0m |
| Flash Metering System |
Pre-flash TTL |
| Flash Modes |
Auto / Forced / Prohibited |
| Flash Type |
Built-in Flash |
| Power Consumption |
Operation: HD: 3.1W; STD: 2.9W View Finder Operation: HD: 3.0W; STD: 2.8W |
| Battery Type |
InfoLITHIUM with AccuPower Meter System (NP-FV50) |
| Power Requirements |
6.8V/7.2 (battery pack); 8.4V (AC Adaptor) |
| Operating System Compatibility |
Windows XP SP3/Windows Vista SP2 /Windows7 64-bit editions and Starter (Edition) are not supported. The Windows Image Mastering API (IMAPI) Ver. 2.0 or later is required to use the function for creating discs. |
| Dimensions (W x H x D) |
3-5/8 x 3-1/4 x 6" /90 x 82 x 151.5mm (including Lens Hood) |
| Weight |
Main unit only: 12.16oz (345g) |
