| Flash energy |
600 J (100 V: 500 J) |
| F-stop |
At a distance of 2 m / 6.6 feet 100 ISO, reflector P50 // P70: 45 5/10// 32 5/10 (100 V: 45 2/10 // 32 2/10) |
| Flash duration t 0.1 (t 0.5) |
1/420 s (1/1500 s) with mains voltage 110 - 240 V
=> With mains voltage 100 V: about 20 % longer |
| Charging time |
For 100 % of selected energy
230 V / 50 Hz: 0.4 - 1.4 s
120 V / 60 Hz: 0.4 - 1.9 s
100 V / 50 Hz: 0.4 - 3.0 s
Can be switched to slow charge mode |
| Ready display |
Visual and audible (can be switched off), signals when 100 % of selected energy is reached |
| Controls |
Illuminated digital display, LED display as well as dust- and scratch-proof, illuminated silicone keyboard |
| Control range of flash energy |
100 V: 1/3 f-stop less
Over 4 f-stops in 1/10 increments (1:16)
Can be switched to 5 f-stops (1:32) |
| Modelling light |
Halogen max. 300 W |
| Additional functions |
Sequences (serial flashes) up to 50 flashes
Sensibility of the photocell can be reduced |
| Flash release |
Manual release button, photocell and infrared receiver (can be switched off), sync cable, FCM 2, FCC, IRX2, transmitter RFS, transceiver RFS |
| Flash monitoring |
Visual: Dim or boost function of the modelling light during charging
Audible: buzzer |
| Remote control |
By means of the 8 channel RFS Interface (Radio Frequency System) for remote control of the unit by radio from Servor RFS as well as transceiver RFS from PC or Macintosh computer. Up to 8 units can be controlled Per channel (studio), there can be controlled up to 8 units. |
| Operational distance outdoors |
Up to 30 m / 98.4 feet |
| Operational distance in closed rooms |
Up to 20 m / 65.6 feet |
| Range |
Up to 300 m / 984 feet |
| Number of sync sockets |
2 |
| Stabilized flash voltage |
+/- 1.5% |
| Cooling |
Fan |
| Power requirements |
200-240 V / 50-60 Hz: 6 A
100-120 V / 50-60 Hz: 10 A |
| Dimensions (L x W X H): Monolight |
286 x 154 x 194 mm / 11.2 x 6 x 7.6 inch |
| Weight: Monolight |
3.3 kg / 7.3 lb |
