| Display Technology |
0.59" LCD w/ MLA |
| Light Output(Lumens) |
3500 normal / Eco = approx. 75% of normal mode |
| Resolution |
Native: WXGA 1280 x 800 Maximum: UXGA 1600 x 1200 |
| Contrast Ratio (up to) |
2000:1 |
| Lamp Type |
265W AC / 195W eco |
| Lamp Life (up to) |
3000 hours normal / 3500 hours eco |
| Screen Size (diagonal) |
25 to 300" |
| Throw Ratio |
1.3 to 2.2 |
| Projection Distance |
2.3 to 47.8 ft. / 0.69 to 14.6m |
| Projector Angle |
0 to 9.8deg. tele / 0 to 16.5deg. wide |
| Lens |
Zoom: 1.7 Focus: Manual F number, fnumber: F=1.7 to 2.1, f=17.4 to 29mm |
| Keystone Correction |
Automatic or manual +/- 30deg. |
| Scan Rate |
Horizontal: 15-100 kHz Vertical: 50-120 Hz |
| Supported Video Standards |
NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM |
| SD/HD Video Signal Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p, Y/Cb/Cr component (with optional adapter - ADP-CV1E) |
| PC Signal Compatibility |
VGA, SVGA, XGA, SXGA, SXGA+, UXGA |
| Macintosh Compatibility |
Yes |
| Input/Output Terminals |
RGB1(analog): VGA 15-pin D-sub RGB2(analog): VGA 15-pin D-sub RGB3(digital): HDMI Video 1: RCA Video 2: S-Video Audio 1: 1/8 in. stereo Monitor out: VGA 15-pin D-sub Audio out: Yes (variable) |
| Audio |
10W speaker |
| External Control |
RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN |
| Sync Compatibility |
Separate Sync / Composite Sync / Sync on G |
| Networking |
RJ-45 Monitoring |
| Power Requirements |
100-240V AC, 50/60 Hz |
| Input Current |
3.9A/1.7A |
| Power Consumption |
358W / 271W / 9W / 0.2W (Normal/ECO Mode/Standby/Standby Power Saving) |
| Operating Temperature |
41-104deg.F / 5-40deg.C |
| Humidity |
20-80% non-condensing |
| Storage |
-14-122deg.F / -10-50deg.C |
| Fan Noise |
36 dB normal / 30 dB eco |
| Regulations |
UL60950-1, CSA60950-1, FCC Part 15 Class B, ICES-03 Class B, NOM-001-SCFI-1993 |
| Installation Orientation |
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear |
| Dimensions (W x D x H) |
15.7 x 11.1 x 4.5 in. / 398.7 x 281.94 x 114.3mm |
| Weight |
8.6 lbs. / 3.9 kg |
