Zoom B2.1u Bass Effects Pedal with XLR Jack Output
Zoom
Zoom B2.1u Bass Effects Pedal ZB21U
SKU: ZOZB21U MFR: ZB21U
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
Fundamental frequencies of an electric bass of about 40 to 600 Hz, but harmonics go all the way up to the ultrasonic frequency range. Many conventional pedal effects make the low end sound thin and lifeless. This usually is not only because of insufficient response in that range, but also because the harmonics are not handled properly. The B2.1u makes such problems history. A 24-bit resolution and a sampling frequency of 96 kHz ensure signal processing power on a par with the best rack-mount devices. The dynamic, wide-range bass signal retains its full impact and the result is clear, powerful sound that remains a distinct presence also when playing in a band ensemble.
The heart of any multi-effect device is its processor and decoder section. Zoom elevates performance to the next level with its newly developed ZFX-3 chip. 32-bit architecture means outstanding accuracy and smooth and detailed signal processing. Fine nuances of fingering and touch come through without any deterioration.
Sophisticated bass amp modeling allows you to adjust parameters such as speaker cabinet characteristics and low-range response in three levels. Get the dynamic, high-impact bass sound of a large cabinet even with flat-response systems. This is handy when using headphones or studio monitors, or when playing through a small combo amp or other bass amp with low output power. Alternatively, turn the cabinet effect off and use only the characteristics of the amp head. Create your very own bass amp sound and get it whenever and wherever you want, even when using a series of different bass amplifiers on stage.
- Six-band linear EQ or two-band parametric EQ offer total flexibility: This ensures the shortest possible route from creative idea to actual sound. Further flexibility is offered by the possibility to switch to a two-band parametric EQ, for delivering a pin-point boost or cut
- Two bass synthesizer types with different filtering and internal waveform: The full-fledged bass synthesizer uses the built-in DSP sound source triggered by the input bass sound
- 13 different bass amp and stomp box modeling choice: By digitally simulating the clipping action of analog devices such as tubes and diodes, the unit faithfully duplicates the characteristics of tube amps and vintage effects
- 47 high-quality effects implemented with 32-bit processing: Nine modules dedicated to aspects such as dynamics, drive, modulation and ambience offer a total of 47 effects
- The right tools for the job - editing controls with analog feel: The three rotary knobs let you tailor three different parameters at the same time. Control sensitivity, attack and level for the compressor effect, or time, feedback and mixing level for the delay effect
- 40 ready to use preset patches for stage and studio: The unit comes preprogrammed with settings for duplicating well-known amps and stomp boxes, settings that are modeled on the signature sound of famous bass players, as well as totally original Zoom effect sound creations
- World's fastest patch change speed (8 ms): The annoying slight muting interval of old when switching patches has been all but eliminated. With its record-setting speed of 0.008 seconds, the B2 series never misses a beat
- Built-in auto-chromatic tuner also supports multi-string bass: The bass guitar tuner can be called up instantly by pushing two foot switches together. High-brightness LED indicators make the note readout easy to see also on a dark stage
- ZNR keeps playing pauses really quiet: The built-in ZOOM Noise Reduction (ZNR) provides optimized performance for bass guitar. While minimizing any alteration of the original sound, ZNR shuts out unwanted noise in the playing pauses
- Integrated drum machine with PCM sound sources: Realistic drum sounds derived from PCM sources are arranged in a variety of rhythm patterns for different musical genres. The 40 rhythm variations include the steady 8-beat of Rock and Pop, funky 16-beat, a "Jazzy" 4-beat and many more choices
- Optional foot switch allows versatile remote operation: When the optional foot switch (FS01) is connected, tap tempo input of settings such as delay time and modulation rate is possible. Other selectable functions include bank switching, drum machine start/stop and delay hold on/off switching
- Ultra low noise design: 120 dB S/N ratio and -100 dB noise floor: Specifications such as a signal-to-noise ratio of 120 dB and noise floor of -100 dB demonstrate a level of performance that is unsurpassed in this class
- Sturdy metal chassis and rubber damping for superior toughness and durability: The combination of a solid metal chassis with shock-absorbent rubber damping ensures that the unit can stand up to the rigors of use on stage
- Two-way power allows use just about anywhere: Thanks to its circuit design optimized for low voltage operation, the unit will run for more than 6 hours on a set of four IEC R6 (size AA) batteries
- Expression pedal adds further versatility to your guitar play: The built-in expression pedal is a great way to control effect parameters in real time. Set the mood with vintage wah, play a pitch shift, or adjust the volume
- XLR output allows direct connection to PA mixer for stage work: Standard XLR connector lets you establish a balanced link, to ensure degradation-free, clean sound transmission also over long cable runs
- USB port enables computer recording: The superb "Cubase LE 4" DAW software comes bundled with the unit, so you can start creating sophisticated music straight away. Because playback from the DAW application can be monitored at the B2.1u itself, there are no latency problems during recording
| Effect Types |
47 |
| Effect Modules |
9 |
| Maximum Simultaneous Effects |
9 |
| Patch Memory |
User 40+Preset 40, Total 80 |
| Sampling Frequency |
96kHz |
| A/D Conversion |
24bit, 64times over-sampling |
| D/A Conversion |
24bit, 128times over-sampling |
| Input |
1/4" phone jack (Rated input level: -20dBm, Input impedance: 1Mohm) |
| Output (Line / headphones combined) |
1/4" stereo phone jack (Maximum output level: +5dBm, Output load impedance: 10kohms or higher) |
| Balanced Output |
XLR jack (Input/output gain: 0dB, Output impedance: 200ohms/HOT-COLD) |
| Control Input |
Expression pedal, Foot switch |
| USB interface |
16bit, 32kHz/44.1kHz/48kHz |
| Display |
2 digit 7segment LED display, Parameter LED, Pedal assign LED |
| Power Requirements |
AA size (LR6) battery x 4, or AC adaptor DC9V/300mA/ Center minus type (AD-0006 recommended) |
| Battery Life |
6hours (with alkaline batteries) |
| Dimensions (W x D x H) |
255 x 165 x 79 mm / 10.03 x 6.49 x 3.11" |
| Weight |
1200 g / 42.3 oz (without batteries) |
