| Standards |
IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u, IEEE 802.3af (PoE), 802.1p (QoS priority), 802.1Q (VLAN), 802.1X (security authentication), 802.11i ready (security WPA2), 802.11e ready (wireless QoS), 802.11F (wireless roaming) |
| Ports |
10BASE-T/100BASE-TX Ethernet, 12V DC power |
| Buttons |
Reset |
| Cabling type |
Unshielded twisted pair (UTP) Category 5 |
| LEDs |
Power, PoE, Wireless, Ethernet |
| Operating system |
Linux |
| Web user interface |
Built-in web user interface for easy browser-based configuration (HTTP/HTTPS) |
| SNMP versions |
SNMP version 1, 2c, 3 |
| Event logging |
Email notification Remote syslog |
| Web firmware upgrade |
Firmware upgradable through web browser |
| Diagnostics |
Flash, RAM, LAN, WLAN |
| Dynamic Host Configuration Protocol |
DHCP client |
| Access point |
Access point mode, point-to-point bridge mode, point-to-multipoint bridge mode, repeater mode |
| Channels |
Operating channels: 11 North America, 13 most of Europe (ETSI and Japan) |
| Internal antennas |
No |
| Internal antennas |
2 (omnidirectional) 3 dBi SMA detachable |
| Transmit power |
Transmit power (adjustable) @ normal temp range: 802.11b: 18 dBm; 802.11g: 16 dBm |
| Antenna gain in dBi |
3 |
| Receiver sensitivity |
802.11.g: 54MBps @ -72 dBm, 802.11.b: 11MBps @ -85 dBM |
| WEP/WPA/WPA2 |
WEP 64-bit/128-bit, WPA-PSK, WPA2-PSK, WPA-ENT, WPA2-ENT |
| Access control |
Wireless connection control: MAC-based |
| SSID broadcast |
SSID broadcast enable/disable |
| 802.1X |
IEEE 802.1X support |
| Wireless client isolation |
Wireless client devices can be Isolated from each other either within an SSID or between 2 SSIDs |
| QoS |
4 queues WMM wireless priority |
| Power |
12V 1A DC input and IEEE 802.3af compliant PoE max power draw: 3.48W |
| Certification |
FCC, ICES 003, CE |
| Operating temperature |
14 Deg. to 131 Deg.F (-10 Deg. to 55 Deg.C) |
| Storage temperature |
-22 Deg. to 158 Deg.F (-30 Deg. to 70 Deg.C) |
| Operating humidity |
10% to 90%, noncondensing |
| Storage humidity |
5% to 95%, noncondensing |
| Minimum Requirements |
802.11b, 802.11g wireless adapter with TCP/IP protocol installed per PC Switch/router with PoE support or PoE injector when used with PoE Web-based configuration: Java-enabled web browser |
| Dimensions (W x H x D) |
8.66 x 6.69 x 1.50 in. (220 x 170 x 38 mm) |
| Weight |
1.69 lb (0.765 kg) |
