G-Technology GSPESPRO4TB 4TB G-Speed eS Pro Hard Drive
G-Technology 4TB G-SPEED eS PRO External Hard Drive Array 0G00166
SKU: GTEGSP4TB MFR: 0G00166
What's Included
What's Included With This Item:
- G-Technology 4TB G-SPEED eS PRO External Hard Drive Array
- 4 x Removable Disk Modules
- AC Cables
- 6' (2 m) Locking mini-SAS Cable
- Software CD-ROM with User Manual and Drivers
- G-Technology Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The 4TB G-SPEED eS PRO External Hard Drive Array from G-Technology is an external hard drive array, designed for use in mission-critical applications. As configured, the array offers an impressive 4TB of storage spread across 4 physical drives.
The array features no internal hardware RAID controller and as such requires a dedicated mini-SAS RAID controller to function. G-Technology's optional PCI Express x8 controller card can host 2 G-SPEED eS PRO units. It is capable of RAID 0, 1, 3, 5 and 6 configurations.
- G-Technology 4TB G-SPEED eS PRO External Hard Drive Array
- 4 x Removable Disk Modules
- AC Cables
- 6' (2 m) Locking mini-SAS Cable
- Software CD-ROM with User Manual and Drivers
- G-Technology Warranty
- High-speed, low-cost RAID designed specifically for professional content creation applications
- Whisper quiet aluminum enclosure features (4) hot-swappable drives and 12Gbps mini-SAS connectivity
- Supports multi-stream SD, ProRes 422, uncompressed HD & 2K DPX workflows
- Requires an optional mini-SAS RAID controller card for operation, this unit is perfect for anyone who already has a G-SPEED eS PRO system and would like to add a 2nd array to their existing controller card
- Four hot-swappable Hitachi Deskstar 7200rpm, 3.5" 3Gbps SATA drives each with up to 32MB cache
- Storage capacities up to 8TB per unit - scalable to 16TB
- Web-based configuration and management
- Auto-rebuild and email notification
- Removable smart cooling fan ensures quiet, reliable operation and data integrity
- Unique industrial design, compact all aluminum enclosure
- Compatible with Mac and Windows systems
| Storage Capacity |
4TB |
| Array Type |
mini-SAS |
| Bays |
4x |
| Drive Types Supported |
SATA II |
| Channels |
1x |
| Sustained Data Transfer Rate |
4-Drive: RAID 0: 405.7MB/sec (Read), 423.6MB/sec (Write), RAID 5: 302.5MB/sec (Read), 311.3MB/sec (Write)
8-Drive (Requires 2 G-SPEED eS PRO units): RAID 0: 782.6MB/sec (Read), 831MB/sec (Write), RAID 5: 678.3MB/sec (Read), 730.4MB/sec (Write), RAID 6: 584.9MB/sec (Read), 619.2MB/sec (Write) |
| Video Stream Playback |
ProRes 422 HQ, Uncompressed 10-bit HD (Single Unit RAID 0); Dual Stream Uncompressed 10-bit HD, Single Stream 2K DPX (Dual Unit RAID 3 or 5) |
| Array Configuration |
RAID via optional controller card |
| RAID |
Type: RAID
Levels Supported: 0, 1, 3, 5, 6 |
| Desktop/Rackmount |
Desktop |
| Status Indicator |
LED |
| Input and Output Connectors |
1x mini-SAS |
| Fan |
2x Removable Smart Cooling Fans |
| System Requirements |
Operating System: Mac OS X; Windows 2000, XP, Vista
Host Adapter: G-Technology mini-SAS RAID Controller |
| Electrical Requirements |
AC: 100-240VAC
Power Consumption: 200W |
| Dimensions (W x H x D) |
4.9 x 6.5 x 8.25in / 12.4 x 16.5 x 21cm |
| Weight |
12.5lbs / 5.7kg |
