Maxell 4 Bay Storage Tower with 2 iVDR and 2 SATA Trays
Maxell 4 Bay Storage Tower 261803
SKU: VDMX261803 MFR: 261803
What's Included
What's Included With This Item:
- Maxell 4 Bay Storage Tower with 2 iVDR and 2 SATA Trays
- 3 Foot eSATA Cable
- Maxell 1 Year Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
Maxell 4 Bay Storage Tower installed in a combination of two iVDR-EX Cartridges and two 3.5" / 2.5" SATA tray. Hard drives are installed into trays and can be easily added or removed, like a tape cartridge, from the system. Hard drives are installed into trays and can be easily added or removed, like a tape cartridge, from the system. A key lock inhibits unauthorized removal of any drive tray enclosure from the system for added security. The Storage Tower interfaces to computers via a built-in Hardware Port Multiplier (HPM) to form a large-capacity and high-performance external RAID system with redundancy to protect against data loss due to drive failure. Once the HPM is configured, the entire RAID set can be attached to any eSATA or USB port of any system. The Storage Tower supports JBOD and standard RAID modes (0, 1, 3, 5 and 10) for data protection and redundancy. To ensure efficient cooling, the Storage Tower includes high capacity cooling fan(s) and two ventilated side panels. The side panels are easily removable to provide access for optional device configurations.
- Maxell 4 Bay Storage Tower with 2 iVDR and 2 SATA Trays
- 3 Foot eSATA Cable
- Maxell 1 Year Warranty
- Great for variety of storage applications- external RAID storage, Video storage, Server storage
- Connect to any system via eSATA (connecting cable included) or USB port
- Hard drives are installed into drive trays that can be added or removed like tape from each drive bay
- Standard SATA drives and iVDR-EX cartridges can be configured to appear as individual drives to any system -requires connecting to a HPM compatible eSATA port or USB port
- RAID configurable via bundled software utility for Windows OS or via onboard jumpers for other OS's
- Once configured, the tower can be connected to any system running any OS (with the exception of individual drive setting that requires an HPM compatible controller)
- Stylish clear acrylic exterior
- Attractive black metal frame with carrying handle
- Light weight, sturdy aluminum construction
- RAID diagnostic via LED lights or the included monitoring software for Windows OS
| No of Trays |
2 iVDR and 2 SATA Trays |
| Supported Storage Devices |
iVDR-EX Cartridge, SATA Hard Drive |
| Connection to System |
1 - eSATA or USB 3.0 / 2.0 connection with USB 3.0 eSATAp adapter |
| Supported Operating Systems |
Connect to any system (OS independent) |
| Construction |
Sturdy aluminum |
| 80 x 80mm cooling fans |
1 |
| Power Supply |
220 Watts 110/220V input |
| Operating Humidity |
0deg. C - 50deg.C, 15% - 90% RH |
| Operating Temperature |
20% - 80%, 0% - 95% RH non-condensing |
| Dimensions (W x D x H) |
8.19 x 12.94 x 8 inch / 20.80 x 32.86 x 20.32 cm |
| Weight |
15 lb (6.8 kg) |
