| System Frequency Response |
35Hz - 20kHz (-6dB) |
| Satellite Max Recomnd Amplifier Power |
100 Watts |
| Satellite Impedance |
8 Ohms nominal |
| Satellite Sensitivity |
86dB @ 1 Watt/1 meter |
| Satellite Frequency Response |
110Hz - 20kHz (-6dB) |
| Satellite High-Frequency Driver |
1/2" (13mm) Titanium-laminate dome, video-shielded |
| Satellite Midrange Driver |
3-1/2" (75mm) Driver, video-shielded |
| Center Channel Max Recmd Amplifier Power |
100 Watts |
| Center Channel Impedance |
8 Ohms nominal |
| Center Channel Sensitivity |
88dB @ 1 Watt/1 meter |
| Center Channel Frequency Response |
100Hz - 20kHz (-6dB) |
| Center Channel High-Frequency Driver |
1/2" (13mm) Titanium-laminate dome, video-shielded |
| Center Channel Midrange Driver |
Dual 3-1/2" (75mm) drivers, video-shielded |
| Subwoofer Amplifier Power (RMS) |
125 Watts |
| Subwoofer Frequency Response |
35Hz - 120Hz (-6dB) |
| Subwoofer Low-Frequency Driver |
8" (200mm) Woofer, bass-reflex enclosure |
| Satellite Dimensions (H x W x D) |
6" x 6-3/8" x 3-7/8" (152mm x 162mm x 98mm) |
| Center Channel Dimensions (H x W x D) |
5-1/4" x 11-3/8" x 3-3/8" (133mm x 289mm x 86mm) |
| Subwoofer Dimensions (H x W x D) |
16-1/4" x 12" x 13-5/8" (413mm x 305mm x 346mm) (including feet) |
| Satellite Dimensions Weight |
2.0 lb (0.9kg) |
| Center Channel Weight |
3.2 lb (1.5kg) |
| Subwoofer Weight |
38 lb (17.3kg) |
| Warranty |
JBL 5 years warranty |
