| Frequency Range (-10 dB) |
50 Hz - 19 kHz |
| Frequency Response (±3 dB) |
55 Hz - 17 kHz |
| Coverage Pattern |
100Deg. x 100Deg. |
| Directivity Factor (Q) |
7.1 |
| Directivity Index (DI) |
8.5 dB |
| Crossover Modes |
Bi-amp/Passive switchable |
| Passive Crossover Slopes |
4th order (24 dB/oct) Transitional HP & LP, 1.3 kHz |
| Transducer Power Rating (AES) |
LF: 300 W (1200 W peak), 2 hrs
250 W (1000 W peak), 100 hrs
HF: 50 W (200 W peak), 2 hrs |
| Long-Term System Power Rating (IEC) |
Passive mode: 250 W (1000 W peak), 100 hrs |
| Maximum SPL |
Bi-amp mode:
LF: 120 dB-SPL cont avg (126 dB peak)
HF: 126 dB-SPL cont avg (132 dB peak)
Passive mode:
120 dB-SPL cont avg (126 dB peak) |
| System Sensitivity (1W @ 1m) |
Passive mode: 95 dB SPL |
| Low Frequency Driver |
1 x JBL M112-8 300 mm (12 in) driver with 63 mm (2.5 in) voice coil |
| Low Frequency: Nominal Impedance |
Transducers: 8 ohms |
| Low Frequency: Sensitivity |
Transducers: 95 dB SPL (1W @ 1m, within operational band) |
| High Frequency Driver |
Transducers: JBL 2418H-1/MTA, 38 mm (1.5 in) exit compression driver, 44 mm (1.75 in) voice coil |
| High Frequency: Nominal Impedance |
Transducers: 8 ohms |
| High Frequency: Sensitivity (1W @ 1m) |
Transducers: 109 dB SPL |
| Enclosure |
Trapezoidal with 15 degree side angles, 16 mm (5/8 in) exterior grade 11-ply Finnish birch plywood |
| Suspension Attachment |
15 points (4 top, 4 bottom, 2 each side, 3 rear), M10 threaded hardware. 4 x M8 on rear for Omnimount 60 Series |
| Finish |
Black DuraFlex finish |
| Grille |
Powder coated 14 gauge perforated steel, with acoustically transparent black foam backing |
| Input Connector |
NL4 Neutrik Speakon and CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade plugs. Speakon in parallel with barrier strip for loop-through |
| Environmental Specifications |
Mil-Std 810; IP-x3 per IEC529 |
| Dimensions (H x W x D) |
548 x 355 x 352 mm (21.6 x 14.0 x 13.9 in) |
| Weight |
19.1 kg (42 lbs) |
