| Capacity |
8TB |
| Data Transfer Speed |
Up to 870 MB/s read, 880 MB/sec write, depending on configuration |
| Supported Drive Configurations |
Hardware-based JBOD; RAID 0, 1, 4, 5, 6 and 10 |
| Supported Video Formats |
2K (2048 x 1556) LOG RGB, 10-bit 1080 4:4:4 HD, uncompressed 8-bit 1080i HD, ProRes 422, DV, HDV, DVCPRO and uncompressed SD |
| RAID Bus Interface |
PCI Express x8 |
| RAID External Connectors |
Two mini-SAS |
| RAID Processor |
Intel IOP348 |
| RAID Firmware |
Flash-ROM upgradeable to latest firmware version |
| RAID RoHS Compliant |
Yes |
| Noise |
Fusion DX800RAID: 42 dBA(Ambient Office: 40-50 dBA) |
| Operating System Compatibility |
Mac OS X Version 10.4.8+ (including Snow Leopard)
Windows 7, Vista, Server 2008, Server 2003 and XP Pro
Linux (RedHat ES 3, 4; Suse RedHat ES 3, 4; Suse Linux 9, 9.1, 9.2, 9.3, 10, 10.1 and the following architectures: i386; x86_64 (AMD64, Intel EM64T) |
| Hardware Compatibility |
Mac, Windows, or Linux computer with available x8 (or x4) PCI Express (PCIe) slot |
| Drive External Connectors |
Two mini-SAS |
| Drives Supported |
3 & 1.5 Gb per second Serial ATA; up to 7,200 RPM |
| Power Supply |
300W, 100-240V, 50/60Hz Universal |
| Operating Temperature |
+41 Deg. F to +104 Deg. F (5 Deg. C to +40 Deg. C) |
| Dimensions (W x D x H) |
7.4 x 15.8 x 11.2 in (18.7 x 40.1 x 28.6 cm) |
| Weight |
28.1 lbs / 12.7 kg (with drives) |
