Cavision 0.4x Fish-Eye Adapter Lens for HD Broadcast Cameras #LFA04X86
Cavision 0.4x Fish-Eye Adapter Lens LFA04X86
SKU: CILFA04X86 MFR: LFA04X86
Please note! This is a Special Order Item and is Non Cancelable and Non Returnable. We Charge you when you place your order. Approximate arrival at Adorama 2 - 4 Weeks from date of order.
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
Cavision LFA04X86 is a 0.4x wide angle fixed focal adapter for 2/3" high definition video cameras. Uses Cavision's 9586 clamp-on mount to attach directly onto 82mm ENG lenses (85 or 86mm outside diameter). Can also be used with a traditional bolt-fastening clamp-on ring. Many other wide angle adapters and zoom-through converters available for most types of video cameras including the prosumer range (ie HVX200, XLH1, HD250, Z1/FX1...) and professional 1/2" & 2/3" range.
New single element 0.4x fish-eye for 72mm lenses. New broadcast series attachment lenses with bayonet mount for HVX200, or more affordable screw-on versions
- Provides 60% wider angle of view
- Universal design for use with a variety of different lenses
- New 9586 Clamp-on mount for easy and quick attachment onto camera lens
- Also available for use with traditional bolt fastening clamp-on ring (CR95-85)
| Class |
Broadcast |
| Effect |
0.4X |
| Suitable lens |
86 or 85mm O.D. lens (82mm Filter Thread) |
| Suitable Focal Length for 2/3" |
8.5mm and up |
| Coating |
Multi-coated |
| Zooming |
Fixed focal |
| Focus |
By macro mechanism |
| Aperture |
No light loss |
| Format |
2/3" SD/HD |
| Back mount |
9586 Clamp-on Mount |
| Construction |
1 group, 1 element |
| Finishing color |
Black |
| Optional Accessories |
Lens Support, clamp-on ring |
| Dimensions |
141mm X 50mm(h) |
| Weight |
930g |
| Warranty |
Cavision warranty |
