| Intrusion Detection and Prevention(IDP) |
Routing and transparent (bridge) mode
Zone-based IDP inspection
Customizable protection profile
Protect over 2000 attack
Automatic signature updates
Custom signatures
Protocol anomaly detection and protection
Traffic anomaly detection and protection
Flooding detection and protection
DoS/DDoS protection |
| Anti-Virus |
Support Kaspersky and ZyXEL Anti-Virus
Stream-based Anti-Virus engine
Zone base AV protection
HTTP/FTP/SMTP/POP3/IMAP4 protocol support
Automatic signature updates
No file size limitation
Blacklist/whitelist support |
| Content Filtering |
Social networking control
Web security - ZyXEL safe browsering
URL blocking, keyword blocking
Profile base setting
Exempt list (blacklist and whitelist)
Blocks java applet, cookies and active X
Dynamic URL filtering database (powered by BlueCoat)
Unlimited user licenses support
Customize warning messages and redirect URL |
| Networking |
Routing mode/bridge mode/mixed mode
Layer 2 port grouping
Ethernet/PPPoE
Tagged VLAN (802.1Q)
Virtual interface (alias interface)
Policy-based routing (user-aware)
Policy-based NAT (SNAT)
Dynamic routing(RIP v1/v2, OSPF)
DHCP client/server/relay
Dynamic DNS support
WAN Trunk more than 2 port
Per host session limit
Guaranteed bandwidth
Maximum bandwidth
Priority-bandwidth utilization |
| Authentication |
Local user database
Microsoft Windows active directory integrate
External LDAP/RADIUS user database
Xauth over RADIUS for IPSec IPV
Forced user authentication (transparent authentication)
IP/MAC address binding |
| System Management |
Role-based administration
Multiple administrator login
Multi-Lingual Web GUI (HTTPS/HTTP)
Out-of-band management (AUX)
Object-based configuration
Command line interface (console/web console/SSH/TELNET)
SNMP v2c (MIB-II)
System configuration rollback
Firmware upgrade via FTP/FTP-TLS/Web GUI |
| Logging/Monitoring |
Comprehensive local logging
Syslog (send to up to 4 servers)
E-mail alert (send to up to 2 servers)
Real-Time traffic monitoring
Built-in daily report
Advanced reporting (Vantage Report)
Centralized Network Management (Vantage CNM) manageable |
| System Capacity & Performance |
SPI Firewall Throughput: 100 Mbps
VPN Throughput (3DES): 50 Mbps
UTM Throughput (AV+IDP): 15 Mbps
Unlimited User Licenses
Max. Sessions: 10,000
New Session Rate: 1,000
Max. Concurrent IPSec VPN Tunnels: 5
Max. Concurrent SSL VPN Users: 5
Included SSL VPN Users: 2
Customizable Zone
|
| 10/100/1000 Interfaces (Copper) |
4 x LAN/DMZ, 2 x WAN |
| USB ports |
2 |
| Power Requirements |
Input Voltage: 100 - 240 V AC, 50 - 60 Hz, 1.2 A
Power Rating: 17 W Max |
| Operating temperature |
0deg.C to 40deg.C |
| Storage temperature |
0deg.C to 40deg.C |
| Operating humidity |
20% to 95% (non-condensing) |
| Dimensions (W x D x H) |
243 x 167.10 x 35.5 mm/9.56 x 6.57 x 1.39" |
| Weight |
1.2 Kg/2.6 lbs |
